• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • SIEMENS SIPROTEC 7KE85 Fault Recorder

                                                                                                                    Brand: Siemens
                                                                                                                    Model: SIPROTEC 7KE85
                                                                                                                    Product Type: Fault Recorder / Power Quality Recorder
                                                                                                                    Series: SIPROTEC 5
                                                                                                                    Application: Power System Monitoring / Fault Analysis / Substation Automation

                                                                                                                    Important: The SIPROTEC 7KE85 is primarily a fault recorder, rather than a conventional protection relay. Siemens describes it as a SIPROTEC 5 modular-system fault recorder for generation, transmission, and distribution applications.

                                                                                                                    Product Overview

                                                                                                                    The Siemens SIPROTEC 7KE85 is a modular fault recording and power-quality monitoring device used to capture electrical disturbances, faults, and system events. It can record electrical signals at configurable sampling rates and supports PMU/synchrophasor measurement according to IEEE C37.118.

                                                                                                                    Technical Specifications

                                                                                                                    Parameter	Specification
                                                                                                                    Brand	Siemens
                                                                                                                    Model	SIPROTEC 7KE85
                                                                                                                    Product Type	Fault Recorder
                                                                                                                    Series	SIPROTEC 5
                                                                                                                    Main Function	Fault / Disturbance Recording
                                                                                                                    Sampling Rate	1–16 kHz, configurable
                                                                                                                    Analog Channels	Up to 40
                                                                                                                    Binary Inputs	Up to 43
                                                                                                                    Binary Outputs	Up to 33
                                                                                                                    Storage	16 GB mass storage
                                                                                                                    PMU	IEEE C37.118
                                                                                                                    Power Quality	IEC 61000-4-30
                                                                                                                    Communication	Industrial substation communication
                                                                                                                    Application	Power Generation / Transmission / Distribution

                                                                                                                    Siemens specifies flexible I/O configurations, with the current 7KE85 supporting up to 40 analog channels, 43 binary inputs and 33 binary outputs.

                                                                                                                    Main Features

                                                                                                                    • Event-triggered and continuous fault recording
                                                                                                                    • Configurable sampling from 1 kHz to 16 kHz
                                                                                                                    • Up to 16 GB mass storage
                                                                                                                    • Power-quality recording according to IEC 61000-4-30
                                                                                                                    • Integrated PMU functionality according to IEEE C37.118
                                                                                                                    • Sequence-of-events recording
                                                                                                                    • Continuous GOOSE message recording
                                                                                                                    • Flexible configuration of binary inputs, outputs and LEDs
                                                                                                                    • Modular SIPROTEC 5 architecture

                                                                                                                    Applications

                                                                                                                    • Electrical substations
                                                                                                                    • Power generation plants
                                                                                                                    • Power transmission systems
                                                                                                                    • Power distribution systems
                                                                                                                    • Grid fault analysis
                                                                                                                    • Power-quality monitoring
                                                                                                                    • Substation automation
                                                                                                                    • Electrical disturbance analysis
