SIEMENS FDOOT241-9 Fire Detection Module

Siemens FDOOT241-9 Fire Detection Module (Multi-sensor Smoke Detector – SINTESO Series)





The Siemens FDOOT241-9 is an addressable multi-sensor fire detector from the SINTESO S-line series. It combines optical smoke detection + thermal sensors to detect both smoldering and fast-flaming fires with high accuracy. It is designed for use in Siemens intelligent fire alarm systems (FDnet / collective systems depending on panel type).

Key Specifications

• Model: FDOOT241-9
• Brand: Siemens
• Series: SINTESO S-line
• Type: Multi-sensor fire detector
• Detection Principle:
  • Optical (scattered light smoke detection)
  • Heat detection (thermal sensors)
• Sensor Configuration: Multi-criteria (smoke + heat)
• Communication: FDnet / system loop (panel dependent)
• Mounting: Plug-in detector head with base (e.g., FDB series)
• Operation Modes:
  • Smoke detection mode
  • Heat detection mode
  • Combined intelligent fire detection mode

What it does (simple explanation)

Smoke / Heat in environment
↓
FDOOT241-9 Detector
↓
Analyzes smoke + temperature patterns
↓
Sends alarm signal to fire panel
↓
Triggers alarm / evacuation system

It is basically:

A smart fire detector that can “think” using multiple sensors

Main Functions

• Detects smoke particles (optical sensing)
• Detects heat rise / temperature change
• Differentiates real fire vs dust/steam (reduces false alarms)
• Sends addressable alarm signal to fire control panel
• Supports intelligent fire detection algorithms (ASAtechnology)

Key Features

• Multi-sensor detection (smoke + heat)
• High false-alarm immunity (ASA signal processing)
• Optical scattering chamber design for accuracy
• Configurable detection modes (smoke / heat / combined)
• Loop-addressable communication system
• Suitable for complex environments (dust, humidity, industrial areas)

Applications

• Office buildings
• Industrial factories
• Warehouses
• Shopping malls
• Hospitals
• Airports
• Hotels and public infrastructure
• High-risk automation environments
