Siemens CP-5611 A2 Communication Card

Siemens CP-5611 A2 Communication Card (PROFIBUS PCI Card)

Product Description
Siemens CP-5611 A2 is a PROFIBUS communication processor card designed for PC-based industrial automation systems. It allows a PC or programming device with a PCI slot to connect to PROFIBUS DP and MPI networks, enabling communication with Siemens PLCs, distributed I/O systems, and industrial automation equipment.

Technical Parameters

• Brand: Siemens
• Model: CP-5611 A2
• Product Type: Communication Processor Card
• Communication Interface: PROFIBUS DP / MPI
• Bus Type: PCI (32-bit)
• Communication Speed: 9.6 kbps to 12 Mbps
• Interface Connector: PROFIBUS RS485 (9-pin Sub-D)
• Supported Systems: SIMATIC S7 PLC, PROFIBUS devices
• Functions:
  • PROFIBUS DP Master/Slave communication
  • MPI communication
  • PG/OP communication
  • S7 communication
• Operating Voltage: 5 V DC (PCI bus supply)
• Installation: PC internal PCI slot
• Application Software: STEP 7, SIMATIC NET, WinCC (depending on configuration)

Advantages & Features

• Original Siemens SIMATIC communication solution
• Provides direct PC-to-PLC PROFIBUS communication
• Supports high-speed industrial fieldbus communication
• Stable data exchange with Siemens automation systems
• Suitable for programming, commissioning, and diagnostics
• Reliable industrial communication performance
• Reduces the need for external communication adapters

Applications

• Siemens S7-300 / S7-400 PLC programming
• PROFIBUS DP network communication
• Industrial automation systems
• Factory production lines
• SCADA and HMI communication systems
• PLC commissioning and maintenance equipment

Notes

• Confirm PC motherboard compatibility with PCI slot before installation.
• Install the correct Siemens communication drivers and software.
• Check PROFIBUS address and communication parameters before use.
• Handle the PCI card with proper ESD protection.
