SIEMENS 7ML6013-1AB10-1AA3 Level Transmitter

SIEMENS 7ML6013-1AB10-1AA3 Radar Level Transmitter

Product Description

The SIEMENS 7ML6013-1AB10-1AA3 is a SITRANS LR250 Radar Level Transmitter designed for continuous, non-contact level measurement of liquids and slurries in industrial applications. Utilizing 25 GHz FMCW radar technology, it delivers accurate and reliable level measurement even under demanding process conditions such as vapor, temperature fluctuations, and turbulence.

Technical Specifications

• Brand: Siemens
• Model: 7ML6013-1AB10-1AA3
• Product Type: Radar Level Transmitter
• Series: SITRANS LR250
• Measurement Principle: 25 GHz FMCW radar (non-contact)
• Application: Continuous level measurement for liquids and slurries
• Maximum Measuring Range: Up to 20 m (65.6 ft)
• Output Signal: 4–20 mA
• Communication: HART protocol
• Power Supply: 24 VDC (loop-powered)
• Process Connection: Threaded connection (configuration dependent)
• Enclosure Protection: IP68 / NEMA 6P
• Display: Local LCD display with programming capability

Advantages & Features

• Non-contact radar measurement with high accuracy
• 25 GHz FMCW radar technology
• Reliable operation in steam, vapor, dust, and turbulent conditions
• 4–20 mA output with HART communication
• Low maintenance due to non-contact sensing
• Easy commissioning with local display and HART configuration
• Rugged industrial design for harsh environments

Applications

• Water and wastewater treatment
• Chemical processing
• Oil and gas storage tanks
• Process vessels
• Food and beverage industries
• Bulk liquid storage
• Industrial process automation

Notes / Precautions

• Verify the process connection and antenna type before installation.
• Ensure the measuring range is suitable for the application.
• Avoid obstructions directly in the radar beam path.
• Configure HART communication parameters according to the control system requirements.
