SIEMENS 7ML5033-1AA00-2A Level Sensor

Siemens 7ML5033-1AA00-2A Level Sensor / Level Controller (MultiRanger 100)





The Siemens 7ML5033-1AA00-2A is a MultiRanger 100 ultrasonic level controller used for non-contact continuous level measurement. It works with ultrasonic sensors to measure liquid, slurry, or solid levels in tanks and open channels, and provides relay outputs for control functions such as alarms and pump control.

This is a wall-mounted control unit, not a direct probe sensor.

Key Specifications

• Model: 7ML5033-1AA00-2A
• Product Type: Ultrasonic Level Controller (MultiRanger 100)
• Measurement Principle: Ultrasonic (non-contact)
• Measuring Range: up to 15 m (50 ft)
• Measurement Type: Single-point level measurement
• Input Voltage: 100–230 V AC
• Output: 6 relay outputs (4 Form A + 2 Form C)
• Function: Level, volume, and open channel flow monitoring
• Communication: Basic version (no SmartLinx module in this variant)
• Mounting: Wall-mounted enclosure

Features & Advantages

• Non-contact ultrasonic measurement (no contact with medium)
• Suitable for liquids, slurries, and solids
• Built-in relay outputs for direct pump/alarm control
• Easy wall-mount installation
• Reliable industrial-grade design
• Can replace multiple point level switches in many applications
• Stable performance for tank monitoring and basic process control

Applications

• Water and wastewater treatment plants
• Chemical and process tanks
• Storage tanks (liquid and slurry)
• Open channel flow monitoring
• Pump station level control
• Industrial process automation

Precautions

• Requires correct sensor alignment and installation height
• Foam, dust, or vapor may affect ultrasonic accuracy
• Not suitable for vacuum or high-pressure closed systems without proper setup
• Electrical installation must follow Siemens wiring diagrams
• Ensure correct configuration in commissioning tool (SIMATIC PDM where applicable)
• Keep transducer surface clean for stable readings
