Siemens 7MF1564-3CB00-1AA1 Pressure Transmitter

Siemens 7MF1564-3CB00-1AA1 Pressure Transmitter

Product Overview

The Siemens 7MF1564-3CB00-1AA1 is a SITRANS P Z Series Pressure Transmitter designed for measuring gauge pressure and absolute pressure of liquids and gases. It uses a high-accuracy piezoresistive measuring cell with stainless steel housing, providing reliable pressure measurement for industrial process applications.

Main Specifications

• Manufacturer: Siemens
• Model: 7MF1564-3CB00-1AA1
• Product Type: Pressure Transmitter
• Series: SITRANS P Z
• Measuring Range: 0...16 bar gauge pressure
• Maximum Operating Pressure: 32 bar
• Output Signal: 4...20 mA (2-wire)
• Power Supply: 10...36 VDC
• Process Connection: G1/2" male (EN 837-1)
• Electrical Connection: DIN 43650 Form A connector
• Sensor Technology:
  • Piezoresistive measuring cell
  • Stainless steel diaphragm
• Seal Material: Viton (FPM)
• Protection Rating: IP65 (depending on configuration)

Advantages & Features

• High measurement accuracy and stability
• Robust stainless-steel construction
• Suitable for liquids, gases, and industrial media
• Temperature-compensated sensor technology
• Compact design for easy installation
• Reliable 4–20 mA signal transmission
• Excellent resistance to industrial environments
• Maintenance-friendly design

Applications

• Process automation systems
• Chemical and pharmaceutical industries
• Water treatment systems
• Mechanical equipment
• Hydraulic and pneumatic systems
• Boiler and energy systems
• Industrial pressure monitoring

Important Notes

• Confirm pressure range before installation.
• Ensure the medium compatibility with sealing materials.
• Check correct power supply and wiring polarity.
• Install according to process connection requirements.
• Avoid excessive pressure beyond rated limits.
