SIEMENS 7ME6920-1AA10-1AA0 Flow Sensor

Siemens 7ME6920-1AA10-1AA0 Electromagnetic Flow Transmitter (SITRANS F M MAG 6000)





The Siemens 7ME6920-1AA10-1AA0 is not the flow sensor itself, but a SITRANS F M MAG 6000 electromagnetic flow transmitter. It works together with Siemens MAG series electromagnetic flow sensors (such as MAG 1100, MAG 3100, and MAG 5100W) to form a complete electromagnetic flowmeter.

Key Specifications

• Model: 7ME6920-1AA10-1AA0
• Brand: Siemens
• Series: SITRANS F M MAG 6000
• Type: Electromagnetic Flow Transmitter
• Display: Integrated LCD display with keypad
• Power Supply: 115–230 V AC, 50/60 Hz
• Enclosure: Glass fiber reinforced polyamide
• Protection Rating: IP67 / NEMA 4X/6
• Installation: Compact or remote mounting
• Compatible Sensors:
  • SITRANS F M MAG 1100
  • SITRANS F M MAG 3100
  • SITRANS F M MAG 5100W
• Outputs:
  • 4–20 mA analog output
  • Pulse/Frequency output
  • Relay output
• Optional Communication: Supports plug-in communication modules (HART, PROFIBUS, FOUNDATION Fieldbus, DeviceNet, Modbus, etc., depending on configuration).

What it does (simple explanation)

Flow Sensor

↓

MAG 6000 Transmitter

↓

Processes measurement signal

↓

Displays flow rate

↓

Outputs 4–20 mA / Pulse / Relay

↓

PLC / DCS / SCADA

The transmitter receives the signal from the electromagnetic flow sensor, calculates the flow rate, and sends measurement data to the control system.

Main Functions

• Processes signals from electromagnetic flow sensors
• Measures instantaneous and totalized flow
• Provides local LCD display and configuration
• Outputs analog and digital process signals
• Performs self-diagnostics and error logging
• Supports industrial communication expansion modules
• Includes advanced batch control functions (MAG 6000 series)

Key Features

• High measurement accuracy (up to ±0.2% of reading)
• Advanced digital signal processing
• Automatic SENSORPROM parameter recognition
• IP67/NEMA 4X/6 enclosure for harsh environments
• User-friendly multilingual display
• Suitable for compact or remote installation
• Expandable communication interfaces

Applications

• Water and wastewater treatment
• Chemical processing
• Food and beverage industry
• Mining and metallurgy
• Power generation
• General industrial process control
• Batch filling systems
