SIEMENS 7KM3220-0BA01-1DA0 SENTRON Power Monitoring Device

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •

                                                                                                                                                                                                                                        • The SIEMENS 7KM3220-0BA01-1DA0 is a SENTRON PAC3220 Power Monitoring Device with a 96 × 96 mm LCD display. It measures electrical parameters such as voltage, current, active power, reactive power and frequency, and communicates via Modbus TCP over Ethernet. Siemens lists it as an active product.

                                                                                                                                                                                                                                          Key Technical Specifications

                                                                                                                                                                                                                                          Specification	Details
                                                                                                                                                                                                                                          Manufacturer	SIEMENS
                                                                                                                                                                                                                                          Model	7KM3220-0BA01-1DA0
                                                                                                                                                                                                                                          Series	SENTRON PAC3220
                                                                                                                                                                                                                                          Product Type	Power Monitoring Device
                                                                                                                                                                                                                                          Display	LCD, 96 × 96 mm
                                                                                                                                                                                                                                          Display Resolution / Area	72 × 54 mm display area
                                                                                                                                                                                                                                          Measurement	Voltage, Current, Active Power, Reactive Power, Frequency
                                                                                                                                                                                                                                          Measurement Method	True RMS (TRMS)
                                                                                                                                                                                                                                          Rated Measurement Voltage	690 V Line-Line / 400 V Line-Neutral
                                                                                                                                                                                                                                          Frequency	45–65 Hz
                                                                                                                                                                                                                                          Current Input	X/1 A or X/5 A AC
                                                                                                                                                                                                                                          Communication	Modbus TCP
                                                                                                                                                                                                                                          Ethernet Ports	2 × RJ45 Fast Ethernet
                                                                                                                                                                                                                                          Auxiliary Supply	100–250 V AC/DC ±10%
                                                                                                                                                                                                                                          Front Protection	IP65
                                                                                                                                                                                                                                          Connection	Screw terminals
                                                                                                                                                                                                                                          Installation	Panel mounting
                                                                                                                                                                                                                                          Net Weight	Approx. 0.433 kg

                                                                                                                                                                                                                                          Siemens specifies 2 Fast Ethernet RJ45 interfaces, TRMS voltage/current measurement, and a wide-range 100–250 V AC/DC auxiliary power supply.

                                                                                                                                                                                                                                          Advantages & Features

                                                                                                                                                                                                                                          • SENTRON PAC3220 multifunction power monitoring device
                                                                                                                                                                                                                                          • 96 × 96 mm compact panel-mount design
                                                                                                                                                                                                                                          • Measures key electrical parameters in real time
                                                                                                                                                                                                                                          • Modbus TCP communication via Ethernet
                                                                                                                                                                                                                                          • Dual RJ45 Ethernet ports
                                                                                                                                                                                                                                          • Wide-range AC/DC auxiliary power supply
                                                                                                                                                                                                                                          • IP65 protection on the front
                                                                                                                                                                                                                                          • Suitable for industrial electrical energy monitoring
                                                                                                                                                                                                                                          • Clear LCD display for local monitoring

                                                                                                                                                                                                                                          Typical Applications

                                                                                                                                                                                                                                          • Industrial power monitoring
                                                                                                                                                                                                                                          • Electrical distribution panels
                                                                                                                                                                                                                                          • Factory automation
                                                                                                                                                                                                                                          • Energy management systems
                                                                                                                                                                                                                                          • Building electrical systems
                                                                                                                                                                                                                                          • Motor and machine power monitoring
                                                                                                                                                                                                                                          • SCADA and industrial Ethernet systems

                                                                                                                                                                                                                                          Installation & Usage Notes

                                                                                                                                                                                                                                          • Verify the voltage and current transformer ratios before commissioning.
                                                                                                                                                                                                                                          • Current inputs require compatible X/1 A or X/5 A CT signals.
                                                                                                                                                                                                                                          • Use a 100–250 V AC/DC auxiliary supply within the specified tolerance.
                                                                                                                                                                                                                                          • Install the device in a suitable control panel.
                                                                                                                                                                                                                                          • Configure the Ethernet and Modbus TCP parameters according to the network.
                                                                                                                                                                                                                                          • Ensure correct CT polarity and wiring to obtain accurate measurements.
                                                                                                                                                                                                                                      •

.The structure and details of the product：
