Siemens 7KG9661-2FA00-1AA0 Metering Device

Siemens 7KG9661-2FA00-1AA0 Metering Device (SICAM T Digital Measuring Transducer)

Product Description
Siemens 7KG9661-2FA00-1AA0 is a SICAM T Digital Measuring Transducer designed for electrical power measurement and monitoring applications. It converts measured electrical parameters into standardized output signals and supports Ethernet communication via Modbus TCP for integration into industrial energy management and automation systems.

Technical Parameters

• Brand: Siemens
• Model: 7KG9661-2FA00-1AA0
• Product Type: Digital Measuring Instrument / Transducer
• Series: SICAM T
• Installation: Standard DIN rail mounting
• Display: Without display
• Enclosure Size: 96 × 96 × 100 mm
• Protection Rating: IP20
• Communication Interface: Ethernet with Modbus TCP
• Binary Outputs: 2 channels
• Analog Outputs: 4 channels
• Input: Galvanically isolated current transformer input
• Measurement Functions:
  • Voltage measurement
  • Current measurement
  • Active power measurement
  • Reactive power measurement
  • Apparent power measurement
  • Energy monitoring

Advantages & Features

• High-precision electrical parameter measurement
• Supports industrial Ethernet communication
• Modbus TCP enables easy integration with PLC and SCADA systems
• Galvanically isolated measurement inputs improve safety
• Multiple analog and digital outputs for flexible applications
• Compact DIN rail installation design
• Suitable for continuous power monitoring applications

Applications

• Industrial power monitoring systems
• Energy management systems
• Electrical distribution cabinets
• Factory automation systems
• Power plants and substations
• Building energy monitoring
• Process automation systems

Notes

• Confirm voltage and current transformer ratios before installation.
• Check communication parameters and Modbus settings.
• Ensure correct wiring of measurement inputs and outputs.
• Installation should follow electrical safety requirements.
