SIEMENS 6XV1830-0EH10 PROFIBUS FC Standard Cable GP

Overview

Key Specifications

• Model: 6XV1830-0EH10
• Structure: 2 solid copper conductors (0.65mm diameter), red/green core insulation
• Characteristic impedance: 150 Ω (standard PROFIBUS specification)
• Shielding: Double-layer shielding — aluminum foil overlapped layer + tinned copper braided screen for excellent EMC anti-interference
• Outer sheath: PVC violet jacket, outer diameter 8 mm
• FastConnect compatible: Special cable structure for stripping without extra tools
• Transmission speed: Supports full PROFIBUS DP speed up to 12 Mbps
• Operating temperature: -40 °C ~ +75 °C
• Bending radius: Min 37.5 mm for single bend; min 75 mm for repeated bending
• Max tensile load: 100 N
• Weight: 78 kg/km
• Supply rule: Sold by meter, minimum order 20 m, maximum reel length 1000 m
• Certifications: CE, UL, RoHS, silicone-free (suitable for automotive paint workshops)

Main Functions

1. Physical transmission medium for PROFIBUS DP bus network, delivering control commands, real-time process data and diagnostic signals between master and slave nodes.
2. Double shielding structure effectively isolates electromagnetic interference from inverters, servo motors and heavy machinery, ensuring stable communication.
3. Matches Siemens FastConnect PROFIBUS connectors for fast on-site stripping and wiring, greatly shortening installation time.
4. Continuous meter marking printed on jacket for convenient length measurement during layout.
5. Compatible with full range Siemens PROFIBUS devices: S7-200/300/400 PLC, ET200S remote I/O, SINAMICS drives, OP/TP HMIs.

Advantages

• Standard 150Ω impedance fully compliant with PROFIBUS international standard, avoids communication signal distortion.
• FastConnect quick-strip design cuts wiring labor cost for mass field construction.
• Wide temperature range adapts to harsh environments like metallurgy, water treatment and cold storage workshops.
• Silicone-free material prevents paint contamination in automotive production lines.
• Oil-resistant PVC outer jacket withstands industrial oil and grease splashes.
• Complete double shielding delivers stable bus performance near high-power equipment.
