SIEMENS 6SN1123-1AB00-0CA1 SIMODRIVE Power Module

SIEMENS 6SN1123-1AB00-0CA1 SIMODRIVE Power Module

Product Description

The SIEMENS 6SN1123-1AB00-0CA1 is a SIMODRIVE 611 Power Module designed for Siemens servo drive systems. It is a 2-axis power module used for controlling Siemens servo motors in CNC machines and industrial motion control applications. The module provides power conversion and current regulation for connected servo drives.

Technical Specifications

• Brand: Siemens
• Model: 6SN1123-1AB00-0CA1
• Product Type: SIMODRIVE Power Module
• Series: SIMODRIVE 611
• Number of Axes: 2 axes
• Cooling Type: Internal air cooling
• Rated Current:
  • 24 A (induction motors)
  • 18 A (synchronous motors)
• Peak Current:
  • 32 A (induction motors)
  • 36 A (synchronous motors)
• Transistor Current Limit: 50 A
• DC Link Voltage: 600/625 VDC
• Module Width: 100 mm
• Weight: Approx. 13.5 kg
• Application: Servo motor drive control

Advantages & Features

• Siemens SIMODRIVE 611 reliable servo drive technology
• Supports dual-axis motor control
• High-performance current regulation for precise motion control
• Designed for CNC and automation equipment
• Suitable for continuous industrial operation
• Modular design for easy maintenance and replacement
• Compatible with Siemens SIMODRIVE drive systems

Applications

• CNC machine tools
• Industrial robots
• Servo positioning systems
• Machine automation equipment
• Production lines
• Precision motion control systems

Notes / Precautions

• This module requires a compatible SIMODRIVE 611 drive system and control unit.
• Confirm motor type, rated current, and system configuration before replacement.
• Check firmware and parameter settings after installation.
