Siemens 6SL3985-6TP00-0AA0 Drive Reactor Module

Siemens 6SL3985-6TP00-0AA0 Drive Safety Module

Product Overview

The Siemens 6SL3985-6TP00-0AA0 is a SINAMICS S120 TM54F Safety Terminal Module designed for safety-related motion control applications. It provides fail-safe digital inputs and outputs for integrating external safety functions with Siemens SINAMICS S120 drive systems, helping achieve high-level machine safety requirements.

Main Specifications

• Manufacturer: Siemens
• Model: 6SL3985-6TP00-0AA0
• Product Type: Safety Terminal Module
• Series: SINAMICS S120
• Module Type: TM54F
• Supply Voltage: 24 VDC
• Safety Level:
  • SIL 3 (IEC 61508)
  • PL e (ISO 13849-1)
• Digital Inputs: 8 fail-safe inputs
• Digital Outputs: 4 fail-safe outputs
• Protection Rating: IP20
• Mounting: SINAMICS S120 drive system installation
• Communication:
  • DRIVE-CLiQ interface
• Application: Safety control for drive systems

Advantages & Features

• Supports advanced drive safety functions
• Enables reliable integration of external safety devices
• High safety performance up to SIL 3 / PL e
• Provides multiple fail-safe I/O channels
• Direct integration with SINAMICS S120 systems
• Improves machine protection and operator safety
• Reduces wiring complexity in safety applications
• Designed for industrial continuous operation

Applications

• CNC machine tools
• Robotics systems
• Automated production lines
• Packaging machinery
• Material handling systems
• Industrial motion control equipment
• Safety-related drive applications

Important Notes

• Verify compatibility with SINAMICS S120 hardware configuration.
• Ensure correct 24V DC power supply.
• Configure safety parameters using Siemens engineering software.
• Safety functions must be tested after installation.
• Installation should comply with machine safety standards.
