Siemens 6SL3352-1AE33-1AA1 Drive Control Unit

Siemens 6SL3352-1AE33-1AA1 Drive Control Unit

Siemens 6SL3352-1AE33-1AA1 Drive Control Unit

  • Item NO.:

    6SL3352-1AE33-1AA1
  • Market Price:

    $790
  • Product Origin:

    Germany
  • Color:

    NEW
  • Product weight:

    0.01KG
  • Lead Time:

    In stock

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

                                                                                                                                            •

                                                                                                                                              Siemens 6SL3352-1AE33-1AA1 Power Block (S120 Motor Module Power Unit)

                                                                                                                                              Overview

                                                                                                                                              This part is not an independent control unit, it is a power block spare part for SINAMICS S120 high-power cabinet-type single-axis motor modules, used to replace the internal power conversion unit of the motor module, responsible for DC bus to three-phase AC inversion to drive heavy-duty motors.

                                                                                                                                              It matches S120 cabinet single motor modules with DC bus 510–750 VDC, rated output current 310 A, forced air cooling structure, nickel-plated busbars and anti-corrosion painted circuit board design.

                                                                                                                                              Core Specifications

                                                                                                                                              1. Electrical Parameters
                                                                                                                                                • DC bus voltage range: 510 ~ 750 VDC
                                                                                                                                                • Rated output current: 310 A
                                                                                                                                                • Three-phase AC output for asynchronous / synchronous motors
                                                                                                                                                • Built-in IGBT power unit, integrated current sampling and temperature detection circuit
                                                                                                                                              2. Environmental & Mechanical
                                                                                                                                                • Protection class: IP20 (cabinet internal installation only)
                                                                                                                                                • Operating temperature: 0 ~ +40°C (derating above 40℃)
                                                                                                                                                • Humidity: ≤80% RH, non-condensing
                                                                                                                                                • Max altitude 1000m without power derating
                                                                                                                                                • Cooling mode: forced air cooling
                                                                                                                                              3. Structure
                                                                                                                                                • Integrated power module + busbar assembly
                                                                                                                                                • Standard plug-in replacement design for S120 cabinet motor modules
                                                                                                                                                • Built-in NTC thermistor for power semiconductor overtemperature monitoring

                                                                                                                                              Key Features

                                                                                                                                              1. Factory pre-assembled power spare part, direct replacement without separate power component matching
                                                                                                                                              2. High efficiency power conversion (efficiency up to 98.7%), low heat loss under continuous heavy load
                                                                                                                                              3. Integrated hardware protection logic: overcurrent, short-circuit, overheat, DC bus overvoltage
                                                                                                                                              4. Nickel-plated busbars enhance conductivity and anti-oxidation performance for long-term stable operation
                                                                                                                                              5. Conformal coated PCB, suitable for dusty, mildly corrosive industrial workshop environments
                                                                                                                                              6. Compatible with S120 CU320/CU320-2 control units via DRIVE-CLiQ communication

                                                                                                                                              Applications

                                                                                                                                              Spare power unit for high-power SINAMICS S120 cabinet single-axis drives, widely used in metallurgical rolling lines, mine hoists, large extruders, paper machine main drives, cement kiln main motors and other heavy-duty high-power speed regulation equipment.

The structure and details of the product:
