SIEMENS 6SL3210-1PE24-5AL0 Frequency Converter

Overview

Key Specifications

1. Electrical Parameters

• Input: 3AC 380–480V (-20% ~ +10%), 47–63Hz
• Rated output current: 76A
• Low overload (LO): 22kW, 150% overload for 3s, 110% for 57s
• High overload (HO): 18.5kW, 200% overload for 3s, 150% for 57s
• Output frequency range: 0–550Hz
• Built-in safety STO (Safe Torque Off) function
• Integrated Class A EMC input filter, built-in braking chopper (external brake resistor required)

2. Mechanical & Environmental

• Dimensions (H×W×D): 472 mm × 200 mm × 237 mm
• Protection grade: IP20 (cabinet internal installation only)
• Cooling: Built-in axial fan air cooling
• Operating temperature:
  • HO mode: -20°C ~ +50°C
  • LO mode: -20°C ~ +40°C
• Mounting: Vertical DIN rail mounting
• Compatible CU firmware: V4.7 HF8 and above
• Note: Control unit and operation panel are not included, need separate purchase

3. Control Matching

   Compatible with CU240E-2, CU250S-2 and other standard G120 control units; supports DRIVE-CLiQ connection for encoder feedback.

Main Functions

1. Motor speed & torque regulation

   Supports V/F scalar control and sensorless vector control, stable low-speed high-torque output for fans, pumps, conveyors and processing machinery.
2. Integrated braking circuit

   Built-in brake chopper, quickly consume motor regenerative energy via external brake resistor for frequent deceleration and emergency stop applications.
3. EMC interference suppression

   Onboard Class A filter effectively suppresses conduction interference, meets industrial EMC standards without extra external filter in most cabinet layouts.
4. Safe torque off (STO)

   Safe hardware cut-off of motor torque, meets machine safety standards, reduces external safety relay wiring.
5. Complete multi-level protection

   Overcurrent, overvoltage, undervoltage, overload, overheating, motor overload, short-circuit, ground fault, phase loss and communication fault detection, with fault codes uploaded to PLC/HMI.
6. Multi-network communication

   Cooperate with CU control unit to support PROFIBUS, PROFINET, Modbus TCP for seamless connection to upper PLC automation systems.
7. Energy-saving operation

   Built-in sleep mode for pump/fan loads to reduce no-load power consumption and lower operating costs.

Advantages

• Modular split design (power module + control unit) for flexible maintenance and function upgrade
• Built-in Class A filter and brake chopper reduce external auxiliary component costs
• Wide overload capacity adapts to impact loads such as lifting and conveying equipment
• Compact FSD frame size saves cabinet installation space
• Wide temperature range fits harsh factory, water treatment and metallurgical environments
• Standard DRIVE-CLiQ digital encoder interface for high-precision speed closed-loop control
• Full fault diagnosis system shortens on-site troubleshooting downtime
