SIEMENS 6SL3120-1TE28-5AA3 SINAMICS Motor Module

Product Overview

Brand: Siemens
Model: 6SL3120-1TE28-5AA3
Product Type: Single Motor Module
Series: SINAMICS S120
Format: Booksize
Cooling: Internal air cooling
Application: Servo Drive / Motion Control / Industrial Automation

The SIEMENS 6SL3120-1TE28-5AA3 is a SINAMICS S120 Single Motor Module in Booksize format. It is used with a SINAMICS S120 drive system to control an individual motor and provides three-phase AC output from the DC link. Siemens specifies a 510–720 V DC link and 85 A rated output current.

Technical Specifications

Parameter	Specification
Brand	Siemens
Model	6SL3120-1TE28-5AA3
Series	SINAMICS S120
Module Type	Single Motor Module
Format	Booksize
DC Link Voltage	510–720 VDC
Nominal DC Input	600 VDC
Output	3-phase AC
Rated Output Voltage	400 VAC
Rated Current	85 A
Base-Load Current	68 A
Intermittent Current (S6, 40%)	110 A
Maximum Current	141 A
Type Power Rating	Approx. 46 kW
Cooling	Internal air cooling
Protection	IP20 / UL Open Type
Control Supply	24 VDC
Communication	DRIVE-CLiQ
Dimensions (W×H×D)	Approx. 200 × 380 × 270 mm
Weight	Approx. 15 kg
Mounting	Booksize drive system
Safety	Safety Integrated functions supported

Siemens' current product listing confirms the 85 A rating, 600 V DC input designation, 400 V 3-phase output, Booksize construction, internal air cooling, and DRIVE-CLiQ cable.
