Siemens 6SL3120-1TE23-0AA4 Single Motor Module

Siemens 6SL3120-1TE23-0AA4 SINAMICS S120 Single Motor Module

Product Description

The Siemens 6SL3120-1TE23-0AA4 is a SINAMICS S120 Single Motor Module designed for high-performance servo and motion control systems. It converts DC link power into controlled three-phase AC output, providing accurate speed, torque, and position control for industrial automation applications.

Technical Specifications

• Brand: Siemens
• Model: 6SL3120-1TE23-0AA4
• Product Type: Single Motor Module
• Series: SINAMICS S120
• Design: Booksize format
• Input Voltage: 600 V DC
• Output Voltage: 3-phase 400 V AC
• Rated Output Current: 30 A
• Cooling Method: Internal air cooling
• Communication Interface: DRIVE-CLiQ
• Safety Function: Supports Safety Integrated functions
• Pulse Pattern: Optimized pulse sampling technology

Advantages & Features

• High-precision servo motor control
• Fast dynamic response and stable operation
• Compact booksize design saves cabinet space
• Supports advanced safety functions
• Reliable performance for continuous industrial operation
• Easy integration with SINAMICS S120 drive systems
• Optimized control technology improves motor efficiency

Applications

• CNC machine tools
• Robotics systems
• Automated production lines
• Packaging machinery
• Semiconductor equipment
• Printing and textile machinery
• Precision motion control systems

Notes / Precautions

• Confirm compatibility with the SINAMICS S120 system before installation
• Check DC link voltage and motor specifications
• Ensure correct wiring and grounding
• Protect the module from dust, moisture, and vibration
• Installation and commissioning should be performed by qualified technicians
