SIEMENS 6SL3055-0AA00-4CA5 Control Unit Module

SIEMENS 6SL3055-0AA00-4CA5 AOP30 Advanced Operator Panel

Product Description

The SIEMENS 6SL3055-0AA00-4CA5 is a SINAMICS AOP30 Advanced Operator Panel, designed for commissioning, parameterization, monitoring, and diagnostics of Siemens SINAMICS drive systems. The language-independent operator panel features memory expansion support (Firmware V2.4 or later) and provides a user-friendly interface for configuring and maintaining SINAMICS converters and drive systems.

Technical Specifications

• Brand: Siemens
• Model: 6SL3055-0AA00-4CA5
• Product Type: Advanced Operator Panel (AOP30)
• Series: SINAMICS
• Display: Integrated LCD with keypad
• Power Supply: 24 VDC (20.4–28.8 VDC)
• Current Consumption:
  • <100 mA (without backlight)
  • <200 mA (maximum backlight)
• Communication Interface: RS232 (PPI protocol)
• Memory: Memory expansion support (Firmware V2.4 or later)
• Backup Battery: 3 V CR2032 lithium battery
• Protection Rating: IP20 (inside cabinet), IP55 (front panel)
• Operating Temperature: 0°C to +55°C
• Dimensions (W × H × D): 212 × 156 × 31 mm
• Weight: Approx. 0.56 kg

Advantages & Features

• Designed for Siemens SINAMICS drive systems
• Easy drive commissioning and parameter configuration
• Real-time status monitoring and diagnostics
• Supports firmware V2.4 and later with memory expansion
• Rugged industrial design for control cabinet installation
• Simple menu-driven operation
• Reliable performance for industrial automation applications

Applications

• SINAMICS G130 drive systems
• SINAMICS G150 drive systems
• Industrial motor control
• Motion control systems
• Manufacturing automation
• Machine tools
• Industrial control cabinets

Notes / Precautions

• Compatible only with supported Siemens SINAMICS drive systems.
• Verify firmware compatibility (V2.4 or later) before installation.
• Ensure a stable 24VDC power supply.
• Check communication cable compatibility before commissioning.
