Siemens 6SE7024-7FD61-Z D78 Inverter Control Board

Product Overview

The Siemens 6SE7024-7FD61-Z belongs to the SIMOVERT MASTERDRIVES Vector Control series and is a high-performance inverter drive unit. The suffix "-Z" indicates a special configuration option, and this model is commonly equipped with the D78 option / CUVC control unit (Control Unit Vector Control) for advanced motor control applications.

Note: The complete part number 6SE7024-7FD61-Z refers to the inverter drive configuration, not only a standalone control board. The D78/CUVC is the internal control electronics used for drive control.

Main Specifications

• Manufacturer: Siemens
• Series: SIMOVERT MASTERDRIVES
• Model: 6SE7024-7FD61-Z
• Product Type:
  • AC Drive / Frequency Converter
  • Vector Control Inverter
  • Drive Control Unit (with CUVC option)
• Technology:
  • Vector control
  • Variable frequency drive (VFD)
• Rated Voltage Class: 500–600 V AC
• Rated Output Current: Approx. 46.5 A
• Rated Power: Approx. 30 kW

Technical Specifications

Power Data

• Input Voltage:
  • 3-phase AC 500–600 V
• Output Current:
  • 46.5 A
• Application Power Range:
  • Approx. 30 kW motor applications
• Control Method:
  • Vector control
  • V/f control

Control System

CUVC Control Unit (D78)

Functions include:

• Motor speed regulation
• Torque control
• Current control
• Drive parameter management
• Fault diagnostics
• Communication interface management

Supports:

• Siemens DriveMonitor / Drive ES tools
• SIMOVERT MASTERDRIVES parameter configuration
• Industrial automation integration

Features & Advantages

• High-performance vector control technology
• Precise speed and torque regulation
• Suitable for demanding industrial drive applications
• Reliable Siemens MASTERDRIVES platform
• Supports complex automation systems
• Advanced diagnostics and monitoring
• Designed for continuous industrial operation

Applications

Used in:

• Industrial machinery
• Conveyor systems
• Cranes and hoisting equipment
• Extrusion machines
• Rolling mills
• Pumps and fans
• Process automation systems

Typical applications:

• Variable speed motor control
• High-precision motion control
• Heavy-duty motor applications
