Product Overview

Siemens 6GK5793-8DJ00-0AA0 is not an Industrial Ethernet Switch Module. The correct product name is:

Siemens ANT793-8DJ IWLAN Antenna

It is an industrial wireless LAN (IWLAN) directional antenna used with Siemens SCALANCE W industrial wireless communication systems. It is designed to extend wireless communication range in industrial environments and is commonly used in factory automation, outdoor installations, and large industrial networks.

Main Specifications

• Manufacturer: Siemens
• Model: 6GK5793-8DJ00-0AA0
• Product Type:
  • IWLAN Antenna
  • Industrial Wireless LAN Antenna
  • Directional Antenna
• Series: ANT793-8DJ
• Application:
  • Siemens SCALANCE W wireless systems
  • Industrial Ethernet wireless networks

Technical Specifications

Wireless Parameters

• Frequency Band: 5 GHz WLAN
• Frequency Range: 5.15 … 5.875 GHz
• Antenna Gain: 18 dBi
• Polarization:
  • Vertical and horizontal polarization (dual linear)
• Radiation Pattern: Directional
• Impedance: 50 Ω
• Connector:
  • 2 × N-female connectors

Mechanical Specifications

• Protection Rating: IP67
• Operating Temperature: -45 °C to +70 °C
• Installation:
  • Wall mounting
  • Mast mounting
• Dimensions:
  • Width: approx. 190 mm
  • Height: approx. 190 mm
  • Depth: approx. 30.5 mm
• Weight: Approx. 700 g

Features & Advantages

• Original Siemens industrial WLAN accessory
• High-gain 18 dBi directional transmission
• Dual polarization improves wireless flexibility
• IP67 rugged housing for harsh environments
• Wide temperature range suitable for outdoor applications
• Supports long-distance industrial wireless communication
• Reduces the need for wired Ethernet infrastructure
• Compatible with Siemens industrial wireless solutions

Applications

• Industrial wireless Ethernet networks
• Factory automation communication
• Crane and warehouse systems
• Automated guided vehicles (AGV)
• Remote equipment monitoring
• Outdoor industrial communication
• Manufacturing plants
• Process automation systems

Compatible Equipment

Commonly used with:

• Siemens SCALANCE W IWLAN access points
• Siemens Industrial Ethernet wireless devices
• SIMATIC automation systems
• PROFINET wireless communication networks

Important Notes

• 6GK5793-8DJ00-0AA0 is an antenna, not an Ethernet switch module.
• Requires compatible Siemens IWLAN equipment to operate.
• Check country-specific WLAN frequency approvals before installation.
• Correct antenna alignment is required for maximum communication distance.
• Use suitable RF cables and connectors to minimize signal loss.
