Specifications

• Channels: 8 analog inputs, galvanically isolated per channel
• Input Types (per channel configurable):
  • Voltage: ±80 mV, ±250 mV, ±5 V, 0–10 V
  • Current: 0–20 mA, 4–20 mA
  • RTD (热电阻): Pt10/50/100/500/1000, Cu10/50/100, Ni10/100/1000, Pt200/500/PtC
  • TC (热电偶): B, C, E, J, K, N, R, S, T, TXK/TXK (L)
• Resolution: 16‑bit (voltage/current); up to 21‑bit (RTD/TC)
• Accuracy: ±0.1% of full scale (at 25 °C)
• Common‑Mode Voltage: 30 V AC / 60 V DC
• Diagnostics: Wire break, over/under range, short circuit
• Alarms: Hardware interrupts, process alarms (4 limits/channel)
• Calibration: Supported during RUN (no downtime)
• Power Supply: 24 V DC (19.2–28.8 V DC)
• Power Consumption: 1.9 W typ.; 55 mA @ 24 V DC
• Dimensions (W×H×D): 35 × 147 × 129 mm
• Weight: ~0.35 kg
• Operating Temperature: 0 °C to +60 °C (horizontal mounting)
• Certifications: CE, UL, RoHS
• Compatibility: TIA Portal ≥ V14, STEP 7 ≥ V5.5 SP3

Key Features

1. Multi‑Signal Support: One module handles voltage, current, RTD and TC for maximum flexibility。
2. High Precision: 16‑bit (up to 21‑bit for temperature) and 0.1% accuracy for precise process measurement。
3. Channel Isolation: Per‑channel galvanic isolation reduces crosstalk and noise。
4. Run‑Time Calibration: Calibrate without stopping the process。
5. Comprehensive Diagnostics: Enables predictive maintenance and quick troubleshooting。

Applications

• Temperature monitoring (RTD/TC) in chemical, pharmaceutical, food & beverage industries
• Process control (pressure, flow, level via voltage/current transmitters)
• High‑precision measurement in factory automation and energy management
• Integration with ET200MP distributed I/O systems
