SIEMENS 6ES7522-1BL01-0AB0 SIMATIC S7-1500 Digital Output Module

Item NO.:
6ES7522-1BL01-0AB0
Market Price:
$500
Product Origin:
Germany
Color:
NEW
Product weight:
0.01KG
Lead Time:
In stock

The SIEMENS 6ES7522-1BL01-0AB0 is a SIMATIC S7-1500 DQ 32x24 V DC/0.5 A HF digital output module with 32 transistor outputs. It provides high-density 24 V DC output control, channel diagnostics, substitute values, and actuator switching-cycle monitoring.

Key Technical Specifications

Specification	Details
Manufacturer	SIEMENS
Model	6ES7522-1BL01-0AB0
Series	SIMATIC S7-1500
Product Type	Digital Output Module
Module Type	DQ 32x24 V DC/0.5 A HF
Digital Outputs	32
Output Groups	4 groups × 8 channels
Output Voltage	24 V DC
Rated Output Current	0.5 A/channel
Max. Current per Group	4 A
Output Type	Transistor, sourcing
Short-Circuit Protection	Electronic
Output Delay ON	Max. 100 µs
Output Delay OFF	Max. 500 µs
Lamp Load	Max. 5 W
Diagnostics	Single-channel diagnostics
Switching Cycle Counter	Yes
Substitute Value	Yes
Power Consumption	1.1 W from backplane bus
Typical Power Loss	3.5 W
Max. Current Consumption	60 mA
Safety Shutdown	Up to SIL 2 / PL d
Net Weight	Approx. 0.321 kg
Front Connector	Ordered separately
Product Status	Active

The module supports safety-oriented shutdown of load groups up to SIL 2 and Category 3 / PL d, subject to the applicable system configuration.

Advantages & Features

32-channel high-density digital output module
24 V DC / 0.5 A per output
Electronic short-circuit protection
Individual channel diagnostics
Integrated actuator switching-cycle counter
Substitute-value function
Supports isochronous operation
Suitable for safety-oriented load-group shutdown
Designed for SIMATIC S7-1500 / ET 200MP systems
Compact and reliable industrial design

Typical Applications

PLC output control
Solenoid valve control
Contactor and relay control
Indicator and signal lamps
Conveyor and material-handling systems
Machine automation
Factory production lines
Industrial control cabinets

Installation & Usage Notes

Use a 24 V DC supply suitable for the connected loads.
Maximum output current is 0.5 A per channel and 4 A per 8-channel group.
The front connector is not included and must be ordered separately.
Ensure adequate protection and wiring for inductive loads.
Configure the module through the appropriate SIMATIC engineering environment.
Observe Siemens installation and safety requirements when using the safety shutdown functions.
