Siemens 6ES7522-1BL01-0AB0 Digital Output Module

6ES7522-1BL01-0AB0
6ES7522-1BL01-0AB0

Siemens 6ES7522-1BL01-0AB0 Digital Output Module

Siemens 6ES7522-1BL01-0AB0 Digital Output Module

  • Item NO.:

    6ES7522-1BL01-0AB0

  • Market Price:

    $860

  • Product Origin:

    Germany

  • Color:

    NEW

  • Product weight:

    0.01KG

  • Lead Time:

    In stock
Inquire Now

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

      •
                                          •

                                            • Siemens 6ES7522-1BL01-0AB0 | S7-1500 Digital Output Module

                                              Manufacturer: Siemens

                                              Model: 6ES7522-1BL01-0AB0

                                              Series: SIMATIC S7-1500 / ET200MP

                                              Type: 32‑channel high‑feature (HF) digital output module, 24 V DC, 0.5 A per channel


                                              Specifications

                                              • Channels: 32 outputs, grouped as 4 × 8 channels
                                              • Output type: Transistor, sourcing (PNP)
                                              • Rated voltage: 24 V DC (19.2–28.8 V DC)
                                              • Rated current: 0.5 A per channel, 4 A per group, 16 A total
                                              • Switching frequency: Up to 100 Hz (resistive load); 10 Hz (lamp load); 0.5 Hz (inductive load)
                                              • Protection: Short‑circuit, overload, reverse‑polarity protection
                                              • Diagnostics: Single‑channel diagnostics, wire break, short circuit, substitute value output
                                              • Safety: SILCL2 (EN 62061), Cat.3 / PL d (EN ISO 13849‑1)
                                              • Power consumption: 1.1 W (backplane), typ. 3.5 W (total)
                                              • Dimensions (W×H×D): 35 × 147 × 129 mm
                                              • Weight: Approx. 0.28–0.32 kg
                                              • Operating temperature: 0 °C to +60 °C
                                              • Front connector: Sold separately (e.g., 6ES7592‑1BM00‑0XB0 push‑in)

                                              Key Features

                                              1. High density: 32 channels in 35 mm width, saves cabinet space
                                              2. Single‑channel diagnostics: Precise fault localization for each output
                                              3. Safety‑rated: Suitable for safety‑related applications up to SIL2 / PL d
                                              4. Fast response: Supports isochronous mode (min. 70 µs TCO)
                                              5. Robust protection: Electronic short‑circuit protection per channel

                                              Applications

                                              • Driving solenoid valves, contactors, relays, indicators
                                              • Machine automation, packaging lines, material handling
                                              • Process industry (on/off valves, motor starters)
                                              • Safety‑related systems requiring SIL2 / PL d

The structure and details of the product：
