Siemens 6ES7222-5BH50-0XB0 Digital Output Module

Siemens 6ES7222-5BH50-0XB0 SIMATIC S7-1200 Digital Output Module

Product Description

The Siemens 6ES7222-5BH50-0XB0 is a SIMATIC S7-1200 SM 1222 Digital Output Module designed to expand PLC output capacity. It provides 16 digital transistor outputs for controlling actuators, valves, relays, and other industrial devices in automation systems.

Technical Specifications

• Brand: Siemens
• Model: 6ES7222-5BH50-0XB0
• Product Type: Digital Output Module
• Series: SIMATIC S7-1200 G2 / SM 1222
• Digital Outputs: 16 DO
• Output Type: Transistor Output (Source)
• Output Voltage: 24 V DC
• Output Current: 0.5 A per channel
• Power Supply: 24 V DC
• Mounting: DIN rail installation
• Protection Class: IP20
• Communication: S7-1200 backplane bus
• Application: PLC expansion I/O module

Advantages & Features

• Provides additional digital output channels for S7-1200 PLC systems
• Fast and reliable switching performance
• Supports direct control of industrial loads
• Compact design saves control cabinet space
• Easy integration with Siemens TIA Portal environment
• LED status indicators for quick diagnostics
• Suitable for continuous industrial operation

Applications

• Factory automation systems
• Machine control equipment
• Packaging machinery
• Conveyor systems
• Motor and valve control
• Production lines
• Industrial equipment monitoring systems

Notes / Precautions

• Confirm compatibility with the S7-1200 CPU before installation
• Check output voltage and load current requirements
• Ensure correct 24 V DC power supply
• Avoid exceeding the maximum output current
• Protect the module from dust, moisture, and strong vibration
• Configure hardware parameters correctly before operation
