SIEMENS 6ES7214-2BD23-0XB8 Programmable Logic Controller

Product Overview

The SIEMENS 6ES7214-2BD23-0XB8 is a CPU 224XP model from the SIMATIC S7-200 CN series, designed for industrial automation control. It features 14 digital inputs, 10 relay outputs, 2 analog inputs, and 1 analog output, making it suitable for applications requiring basic to intermediate automation tasks such as machine control, process monitoring, and small-scale distributed I/O systems .

Key Features

Compact & High-Performance Control
- 14 digital inputs (24V DC) and 10 relay outputs (supports 24V DC/230V AC) .
- 2 analog inputs (0–10V/0–20mA) and 1 analog output for sensor interfacing and actuator control .
- 12/16 KB program memory and 10 KB data memory, expandable via EEPROM storage module .
Advanced Communication & Networking
- 2 RS-485 ports supporting PPI, MPI, and Freeport protocols for PLC-to-PLC or HMI communication .
- Baud rates up to 187.5 kbps, with MPI network support for S7-300/400 integration .
Motion & High-Speed Control
- 6 high-speed counters (up to 200 kHz) for encoder feedback or pulse counting .
- 2 pulse outputs (100 kHz max) for stepper/servo motor control.
Robust Industrial Design
- Operating temperature: 0°C to +60°C .
- Dimensions: 140 × 80 × 62 mm (W × H × D) .
User-Friendly Programming
- Configurable via STEP 7-Micro/WIN (V4.0+) .
- Password protection (3 levels) for secure program access .

Technical Specifications

Parameter	Specification
Model	6ES7214-2BD23-0XB8
Series	SIMATIC S7-200 CN
Inputs	14 × 24V DC digital, 2 × analog (0–10V/0–20mA)
Outputs	10 × relay (24V DC/230V AC), 1 × analog (0–10V/0–20mA)
Memory	12/16 KB program, 10 KB data
Communication	2 × RS-485 (PPI/MPI/Freeport)
High-Speed I/O	6 × counters (200 kHz), 2 × pulse outputs (100 kHz)
Power Supply	85–264V AC (47–63 Hz)
Certifications	CE
