SIEMENS 6ES7193-6AR00-0AA0 Terminal Module

Siemens 6ES7193-6AR00-0AA0 Terminal Module (ET 200SP BusAdapter / Interface Adapter)





The Siemens 6ES7193-6AR00-0AA0 is an ET 200SP BusAdapter (BA 2×RJ45) used in distributed I/O systems. It is a communication interface adapter, not a power or signal processing module.

It is installed on an ET 200SP Interface Module (IM) and provides PROFINET Ethernet connectivity via dual RJ45 ports.

Key Specifications

• Model: 6ES7193-6AR00-0AA0
• Brand: Siemens
• Series: SIMATIC ET 200SP
• Type: BusAdapter (PROFINET Adapter)
• Interface: 2 × RJ45 Ethernet ports
• Communication Protocol: PROFINET Industrial Ethernet
• Function: Network connection between PLC and ET 200SP station
• Mounting: Plug-in module for ET 200SP Interface Module (IM)
• System Role: Communication layer (not I/O processing)
• Weight: ~50 g class device

What it does (simple explanation)

PLC CPU (S7-1200 / S7-1500)
↓ PROFINET Ethernet
6ES7193-6AR00-0AA0 BusAdapter
↓
ET 200SP Interface Module
↓
ET 200SP I/O Modules (DI / DO / AI / AO)

Main Functions

• Provides PROFINET network connection
• Links ET 200SP station to PLC system
• Enables Ethernet communication via dual RJ45 ports
• Supports industrial network topology (line, star, ring depending system)
• Allows fast replacement without rewiring full station

Key Features

• Dual RJ45 Ethernet ports (IN/OUT topology)
• Industrial PROFINET communication support
• Plug-in design for easy replacement
• Compact and modular structure
• Supports ET 200SP distributed architecture
• High reliability for industrial networking

Applications

• Factory automation networks
• PLC remote I/O systems
• Machine control systems
• Distributed control systems (DCS)
• Industrial Ethernet PROFINET networks
• Production line automation
