Siemens 6ES7138-4DE02-0AB0 IO-Link Master Module

Siemens 6ES7138-4DE02-0AB0 SIMATIC ET 200S Electronic Module

Note: The model 6ES7138-4DE02-0AB0 is not an IO-Link Master Module. It is a SIMATIC ET 200S technological function module for incremental encoder connection.

Product Description

The Siemens 6ES7138-4DE02-0AB0 is a SIMATIC DP ET 200S Counter / Measure Module designed for high-speed acquisition of encoder signals. It supports RS422 incremental encoders and provides measurement and counting functions for precise motion detection in industrial automation systems.

Technical Specifications

• Brand: Siemens
• Model: 6ES7138-4DE02-0AB0
• Product Type: Electronic Technology Module
• Series: SIMATIC ET 200S
• Function: Counter / Measurement Module
• Encoder Connection: RS422 incremental encoder
• Channels: 1 Channel
• Input Frequency: Up to 500 kHz
• Operating Modes:
  • Count mode
  • Measure mode
• Supply Voltage: 24 V DC
• Encoder Supply: 24 V DC
• Encoder Output Current: Max. 500 mA
• Installation Width: 30 mm
• Protection Class: IP20
• Mounting: ET 200S rail system
• Weight: Approx. 65 g

Advantages & Features

• High-speed encoder signal processing up to 500 kHz
• Accurate position and speed measurement
• Supports counting and measurement applications
• Reduces PLC CPU processing load
• Compact ET 200S modular design
• Reliable Siemens industrial automation technology
• Suitable for precise motion control systems

Applications

• CNC machines
• Packaging equipment
• Conveyor systems
• Positioning systems
• Servo and motion control applications
• Production line monitoring
• Industrial measurement systems

Notes / Precautions

• Confirm compatibility with the ET 200S system before installation
• Check encoder type and wiring configuration
• Ensure correct 24 V DC power supply
• Verify RS422 signal connections
• Protect module from dust, moisture, and vibration
• Commissioning should be performed by qualified personnel
