SIEMENS 6ES7134-6GF00-0AA1 Analog Input Module

Siemens 6ES7134-6GF00-0AA1 Analog Input Module (ET 200SP AI 8×I 2-/4-wire BA)





The Siemens 6ES7134-6GF00-0AA1 is a SIMATIC ET 200SP analog input module (AI 8×I 2-/4-wire BA) used in distributed I/O systems. It is designed to measure industrial current signals (mainly 4–20 mA / 0–20 mA) from field sensors such as pressure, temperature, flow, and level transmitters, and convert them into digital values for PLC systems.

Key Specifications

• Model: 6ES7134-6GF00-0AA1
• Brand: Siemens
• Series: SIMATIC ET 200SP
• Module Type: Analog Input Module (AI 8×I 2-/4-wire BA)
• Inputs: 8 analog current inputs (single-ended)
• Signal Types Supported:
  • 4–20 mA
  • 0–20 mA
  • ±20 mA
• Sensor Types: 2-wire and 4-wire transmitters
• Resolution: up to 16-bit (high precision measurement)
• Function: Converts analog signals → PLC digital values
• Mounting: ET 200SP BaseUnit (A0 / A1 compatible)
• System: Works with S7-1200 / S7-1500 via PROFINET ET200SP head module

What it does (simple explanation)

Pressure / temperature / flow transmitter
↓
6ES7134-6GF00-0AA1 (AI module)
↓
Converts 4–20 mA signal into digital data
↓
ET200SP interface module
↓
PLC CPU (S7-1200 / S7-1500)
