SIEMENS 6ES7132-6BH01-0BA0 Digital Output Module

Siemens 6ES7132-6BH01-0BA0 Digital Output Module (ET 200SP, DQ 16×24V DC/0.5A)





The Siemens 6ES7132-6BH01-0BA0 is a SIMATIC ET 200SP digital output module (DQ 16×24V DC/0.5A Standard) used in distributed I/O systems. It converts PLC control signals into 24V DC switching outputs for field devices such as relays, solenoids, lamps, and contactors.

Key Specifications

• Model: 6ES7132-6BH01-0BA0
• Brand: Siemens
• Series: SIMATIC ET 200SP
• Module Type: Digital Output Module (DQ 16x24V DC/0.5A)
• Outputs: 16 channels
• Output Type: 24V DC source (PNP switching)
• Current per Channel: 0.5 A
• Total Current: up to ~8 A (module dependent)
• Mounting: ET 200SP BaseUnit system (DIN rail)
• Diagnostics: short-circuit, wire break, supply voltage monitoring
• Function: Distributed output control via PROFINET system

What it does (simple explanation)

PLC CPU
↓
PROFINET / ET200SP Interface
↓
6ES7132-6BH01-0BA0 Output Module
↓
Turns ON/OFF 24V signals
↓
Drives actuators (relays, valves, contactors, lamps)

It acts like a:

16-channel industrial electronic switch controlled by PLC

Main Functions

• Outputs ON/OFF control signals from PLC
• Drives industrial loads:
  • Relay coils
  • Solenoid valves
  • Contactors
  • Indicator lamps
• Expands remote I/O capacity in ET 200SP systems
• Provides diagnostic feedback for maintenance
• Enables fast switching in automation systems

Key Features

• 16-channel high-density output design
• 24V DC industrial standard outputs
• Source (PNP) transistor switching
• Built-in diagnostics per channel
• LED status indication for each output
• Compact ET 200SP distributed architecture
• High reliability for industrial environments

Applications

• Factory automation systems
• Packaging machines
• Conveyor control systems
• Motor starter control (via contactors)
• Industrial lighting and signaling
• Process control panels
• Distributed PLC I/O stations
