- - SIEMENS 6EP1334-3BA10 Power Supply Module

    Product Overview

    Brand: SIEMENS
    Model: 6EP1334-3BA10
    Product Type: Stabilized DC Power Supply Module
    Series: SITOP PSU200M / SITOP PSU8200
    Application: Industrial Automation Power Supply

    The SIEMENS 6EP1334-3BA10 is a SITOP PSU200M stabilized power supply designed to convert AC input power into a regulated 24 V DC output for industrial automation equipment such as PLCs, sensors, control systems, and communication devices. It provides 10 A output current with a wide input voltage range of 120/230–500 V AC.

    Technical Specifications

    General Data
    - Brand: SIEMENS
    - Model: 6EP1334-3BA10
    - Product Name: SITOP PSU200M 10 A Stabilized Power Supply
    - Series: SITOP PSU8200
    - Type: AC/DC Power Supply
    - Output Voltage: 24 V DC
    - Output Current: 10 A
    - Output Power: Approx. 240 W
    - Mounting: DIN Rail mounting
    - Protection Class: IP20
    Electrical Specifications

    Input Side
    - Input Voltage:
      - AC 120 V
      - AC 230 V
      - AC 400 V
      - AC 500 V
    - Input Type: 1-phase / 2-phase AC
    - Frequency: 50/60 Hz
    - Frequency Range: 47…63 Hz
    Typical input current:
    - At AC 120 V: approx. 4.4 A
    - At AC 230 V: approx. 2.4 A
    - At AC 500 V: approx. 1.1 A
    Output Side
    - Output Voltage: DC 24 V
    - Adjustment Range: Approx. 22.8…26.4 V DC
    - Rated Output Current: 10 A
    - Output Power: 240 W
    - Voltage Regulation: Stabilized DC output
    - Efficiency: Approx. 91%
    Protection Functions

    Built-in protection features:
    - Short-circuit protection
    - Overload protection
    - Overvoltage protection
    - Thermal protection
    - Current limiting function
    Additional functions:
    - LED output status indication
    - "24 V OK" relay contact output
    Performance Characteristics

    Power Failure Buffering
    - Minimum buffering time at rated load: approx. 25 ms
    - Dynamic mains compensation capability
    Overvoltage Resistance
    - Surge withstand capability up to approximately 1300 V peak / 1.3 ms
    Mechanical Specifications
    - Mounting: DIN rail TH35
    - Width: Approx. 70 mm
    - Dimensions: Approx. 70 × 125 × 125 mm
    - Weight: Approx. 0.8 kg
    - Protection Rating: IP20
    Communication & Status Interface

    The module provides:
    - 24 V DC output terminals
    - Input power terminals
    - Status monitoring relay contact
    Status indication:
    - Green LED: 24 V output OK
    - Fault diagnosis through status contact
    Features & Advantages

    High Reliability Industrial Power

    Designed for continuous operation in industrial automation environments.

    Wide Input Voltage Range

    Supports various international AC power systems.

    Stable 24 V DC Supply

    Provides reliable power for:
    - PLC systems
    - I/O modules
    - Sensors
    - Industrial communication devices
    Compact DIN Rail Design

    Easy installation inside control cabinets.

    Siemens SITOP Quality

    Suitable for demanding industrial applications requiring stable DC power.

    Typical Applications
    - PLC control cabinets
    - Industrial automation systems
    - Siemens SIMATIC systems
    - Machine control equipment
    - Robotics systems
    - Sensors and actuators
    - Industrial communication networks
    - Process control systems
    Compatible Equipment

    Commonly used with:
    - Siemens SIMATIC S7 PLC
    - Siemens ET 200 systems
    - HMI panels
    - Industrial Ethernet switches
    - Remote I/O modules
    - Automation controllers
    Installation Precautions
    - Verify AC input voltage before connection.
    - Ensure output polarity (+/-) is correct.
    - Do not exceed 10 A output current.
    - Provide adequate cabinet ventilation.
    - Install on proper DIN rail.
    - Use suitable circuit protection on the AC input side.
    - Disconnect power before maintenance.
