SIEMENS 6ED1052-1FB00-0BA5 LOGO! Logic Module

Product Description

SIEMENS 6ED1052-1FB00-0BA5 is a SIMATIC LOGO! 230RC Logic Module (programmable logic controller / smart relay) designed for small-scale automation and control applications. It integrates digital inputs, relay outputs, display, and programmable logic functions in a compact DIN rail mounting unit.

The module is suitable for simple automation tasks such as lighting control, pump control, HVAC systems, building automation, and small machine control applications.

Specifications

• Brand: SIEMENS
• Model: 6ED1052-1FB00-0BA5
• Series: SIMATIC LOGO!
• Product Type: Logic Module / Programmable Relay Controller
• Model Name: LOGO! 230RC
• Display: Integrated LCD display and keypad
• Power Supply: 115/230V AC/DC
• Digital Inputs: 8 DI
• Digital Outputs: 4 DO (Relay Outputs)
• Output Type: Relay contact
• Memory Capacity: Approx. 130 function blocks
• Expansion: Supports additional LOGO! expansion modules
• Mounting: 35 mm DIN rail mounting
• Application Voltage: 230V AC/DC system applications

Functions

• Executes programmable logic control tasks
• Controls motors, lamps, valves, pumps, and relays
• Provides timer, counter, and logic functions
• Monitors digital input signals
• Controls external devices through relay outputs
• Displays operating status and parameters
• Supports modular expansion for additional I/O

Advantages & Features

• Compact all-in-one automation controller
• Integrated display for local operation and diagnostics
• Simple programming compared with traditional PLC systems
• Reliable Siemens industrial design
• DIN rail installation for control cabinets
• Suitable for cost-effective small automation solutions
• Expandable with LOGO! modules

Applications

• Building automation systems
• Lighting control systems
• Pump and motor control
• HVAC control
• Small machine automation
• Conveyor control systems
• Industrial control panels

Notes

• 6ED1052-1FB00-0BA5 is a LOGO! logic module, not a full S7 PLC CPU
• Requires Siemens LOGO! programming software for configuration
• Check voltage rating before wiring (115/230V AC/DC)
• Verify expansion module compatibility before installation
• This model is discontinued; later LOGO! generations provide updated replacements such as LOGO! 230RC successor versions.
