SIEMENS 6DR5020-0NG01-0AA0 SIPART Positioner

Product Description

SIEMENS 6DR5020-0NG01-0AA0 is a SIPART PS2 Smart Electropneumatic Positioner designed for precise control of pneumatic linear and part-turn valve actuators. It converts a 4…20 mA control signal into pneumatic output pressure to position control valves accurately in industrial process applications.

This model includes a position feedback module (4…20 mA analog output) and is designed for actuator control without explosion protection.

Specifications

• Brand: SIEMENS
• Model: 6DR5020-0NG01-0AA0
• Series: SIPART PS2
• Product Type: Electropneumatic Valve Positioner
• Actuator Type: Pneumatic linear and part-turn actuators
• Input Signal: 4…20 mA (2-wire)
• Communication: HART compatible (depending on configuration)
• Action Type: Double-acting actuator
• Housing Material: Polycarbonate enclosure
• Explosion Protection: Without explosion protection
• Position Detection: Non-contacting position detection (NCS)
• Electrical Connection: M20 × 1.5
• Pneumatic Connection: G 1/4
• Position Feedback Output: 4…20 mA analog position feedback
• Protection Rating: IP66 / NEMA 4X
• Weight: Approx. 0.9 kg

Advantages & Features

• High-precision valve position control
• Fast and stable actuator response
• Supports automatic commissioning and calibration
• Non-contact position sensing reduces mechanical wear
• Suitable for various pneumatic valve actuators
• Compact and rugged industrial design
• Provides reliable operation in harsh process environments
• Supports continuous monitoring and diagnostics

Applications

• Process control systems
• Chemical and petrochemical plants
• Power generation equipment
• Water treatment systems
• Steam and gas control valves
• Industrial automation valve control
• DCS and PLC controlled actuator systems

Notes

• Confirm actuator type and mounting kit compatibility before installation
• Check supply air pressure and pneumatic connections
• Verify 4…20 mA signal wiring before commissioning
• Perform valve calibration after replacement
• Protect the unit from moisture and contamination
• Installation and adjustment should be performed by qualified technicians
