SIEMENS 6AV7863-2TA00-0AA0 SIMATIC Operator Panel

Product Description

SIEMENS 6AV7863-2TA00-0AA0 is a SIMATIC IFP1500 Flat Panel 15" Touch Operator Panel (Industrial Flat Panel Display) designed for industrial visualization and operator control applications. It is used as a touch display terminal connected to an industrial PC or automation system, providing machine operation, monitoring, and process visualization functions.

Note: This model is an industrial touch display (Flat Panel), not a standalone HMI controller with built-in PLC communication functions.

Specifications

• Brand: SIEMENS
• Model: 6AV7863-2TA00-0AA0
• Series: SIMATIC IFP1500
• Product Type: Industrial Flat Panel / Touch Operator Display
• Display Size: 15.4 inch (15")
• Display Type: TFT widescreen display with LED backlight
• Touch Type: Resistive single-touch screen
• Resolution: 1280 × 800 pixels
• Display Colors: 16.7 million colors (24 bit)
• Brightness: Approx. 400 cd/m²
• Contrast Ratio: Approx. 1000:1
• Viewing Angle: 170° × 170°
• Power Supply: 24 V DC
• Voltage Range: 19.2…28.8 V DC
• Interfaces:
  • DisplayPort
  • DVI-D
  • USB touch interface
• Protection Rating: IP65 (front panel)
• Mounting: Panel mounting
• Dimensions: Approx. 415 × 310 × 62.5 mm
• Weight: Approx. 3.9 kg

Advantages & Features

• Large 15" industrial touchscreen display
• High-resolution 1280×800 visualization
• Suitable for harsh industrial environments
• Front panel IP65 protection against dust and water
• LED backlight provides long service life
• Supports connection with industrial PCs and automation systems
• Compact design for control cabinet installation
• Reliable Siemens SIMATIC industrial quality

Applications

• Industrial machine operation terminals
• Factory automation systems
• Production line monitoring
• Industrial PC visualization systems
• Manufacturing equipment
• Process monitoring stations
• Control cabinet display applications

Notes

• Confirm compatibility with the connected industrial PC or controller before installation
• Check DisplayPort/DVI cable type before replacement
• Ensure 24V DC power supply is within specified range
• Avoid damaging the touchscreen surface
• Keep connectors clean and protected
• Follow Siemens installation instructions
