SIEMENS 6AV6545-0DB10-0AX0 SIMATIC HMI Panel

Product Description

SIEMENS 6AV6545-0DB10-0AX0 is a SIMATIC Multi Panel MP370 15" Touch HMI Panel designed for industrial operator control and machine visualization applications. It provides a human-machine interface for monitoring processes, displaying operating data, and controlling automation systems. The panel runs on Windows CE 3.0 and is configured using ProTool V6.0 SP2 or higher.

Specifications

• Brand: SIEMENS
• Model: 6AV6545-0DB10-0AX0
• Series: SIMATIC Multi Panel MP370
• Product Type: HMI Operator Panel / Touch Panel
• Display Type: Color TFT Display
• Screen Size: 15.1 inch
• Resolution: 1024 × 768 pixels
• Display Colors: 256 colors
• Operation: Touchscreen
• Operating System: Windows CE 3.0
• Configuration Software: ProTool V6.0 SP2 or higher
• Communication Interfaces:
  • 1 × TTY
  • 2 × RS232
  • 1 × RS422
  • 1 × RS485
  • 1 × Ethernet (RJ45)
• Dimensions: Approx. 400 × 310 × 69 mm
• Weight: Approx. 5.7 kg
• Mounting: Panel installation

Advantages & Features

• Large 15.1" color TFT display for clear visualization
• Touchscreen operation for convenient machine control
• Supports industrial communication with multiple interfaces
• Reliable Siemens SIMATIC industrial design
• Suitable for complex visualization and operator control tasks
• Easy integration with Siemens PLC systems
• Provides efficient monitoring and control of production processes

Applications

• Factory automation systems
• Machine operation panels
• Production line monitoring
• Process control systems
• Siemens S7 PLC applications
• Industrial equipment visualization
• Manufacturing and assembly systems

Notes

• Confirm compatibility with existing PLC and communication protocol before replacement
• Backup the existing HMI project before changing the panel
• Requires compatible ProTool engineering software for configuration
• Check communication parameters after installation
• Handle the touchscreen and display carefully during transportation
• Ensure correct power supply connection before startup
