SIEMENS 6AV2124-0QC02-0AX0 SIMATIC HMI Panel

Product Description

SIEMENS 6AV2124-0QC02-0AX0 is a SIMATIC HMI TP1500 Comfort Panel from the Siemens Comfort Panels series. It is a 15-inch touch screen operator panel designed for machine operation, visualization, and process monitoring in industrial automation systems.

The TP1500 Comfort provides a user interface between operators and PLC systems, supporting PROFINET and MPI/PROFIBUS DP communication for Siemens automation applications.

Specifications

• Brand: SIEMENS
• Model: 6AV2124-0QC02-0AX0
• Product Type: SIMATIC HMI Operator Panel
• Series: TP1500 Comfort Panel
• Display Size: 15-inch widescreen TFT
• Operation: Touch screen
• Display Resolution: 1366 × 768 pixels
• Display Colors: 16 million colors
• Communication Interfaces:
  • PROFINET Ethernet
  • MPI / PROFIBUS DP
• Configuration Memory: 24 MB
• Software: WinCC Comfort (TIA Portal)
• Mounting: Panel mounting
• Protection Degree: IP65 front protection
• Weight: Approx. 4.4 kg

Functions

• Displays machine operating status and process data
• Provides operator control through touch interface
• Displays alarms, messages, and diagnostics
• Provides visualization of PLC-controlled processes
• Supports recipe management and data logging
• Enables communication between operator and automation system

Advantages & Features

• Siemens SIMATIC high-performance HMI technology
• Large 15-inch industrial touch display
• High-resolution color visualization
• Supports multiple Siemens PLC communication methods
• Integrated alarm and diagnostic functions
• Suitable for demanding industrial environments
• Easy integration with Siemens TIA Portal engineering software

Applications

• Factory automation systems
• Machine control panels
• Production line monitoring
• Packaging machinery
• Process control systems
• Siemens S7 PLC applications
• Industrial equipment operator stations

Notes

• 6AV2124-0QC02-0AX0 is an HMI operator panel, not a PLC controller
• Requires Siemens WinCC software for configuration
• Confirm PLC communication protocol before replacement
• Check project version compatibility before downloading programs
• Ensure correct 24V DC power supply before installation
