SIEMENS 5WG1534-1DB31 KNX Binary Input Module

Item NO.:
5WG1534-1DB31
Market Price:
$500
Product Origin:
Germany
Color:
NEW
Product weight:
0.01KG
Lead Time:
In stock

- - - - SIEMENS 5WG1534-1DB31 KNX Binary Input Module

        Product Overview

        Brand: SIEMENS
        Model: 5WG1534-1DB31
        Product Type: KNX Switching Actuator
        Series: GAMMA instabus KNX
        Application: Building Automation / Lighting Control / Electrical Load Switching

        Note: The model 5WG1534-1DB31 is not a KNX Binary Input Module. It is a KNX Switching Actuator N 534D31 (4-channel AC 230 V actuator). It is used to control electrical loads through KNX bus commands, such as lighting, HVAC valves, and other building equipment.

        Technical Specifications

        General Data

        Brand: SIEMENS

        Model: 5WG1534-1DB31

        Product Name: N 534D31 Switching Actuator

        Series: GAMMA instabus KNX

        Type: Binary Output / Switching Actuator

        Channels: 4 outputs

        Installation: DIN rail mounting

        Communication: KNX TP (Twisted Pair) bus

        Application: Building automation systems

        Output Specifications

        Switching Outputs

        Number of Outputs: 4 channels

        Rated Voltage: AC 230 V

        Rated Current:

        16 AX / 20 AX (depending on load type)

        Load Type Support:

        Resistive loads

        Capacitive loads

        Fluorescent lighting loads

        Electronic ballasts (depending on configuration)

        Typical applications:

        Lighting circuits

        Electrical heating

        Fan control

        Motorized equipment switching

        KNX Communication

        KNX Bus Interface

        Functions:

        Receiving KNX telegram commands

        Switching ON/OFF loads

        Status feedback

        Scene control

        Timer functions

        Logic functions

        The device is powered through the KNX bus and communicates directly with KNX building automation systems.

        Control Functions

        Supports:

        Individual channel switching

        Group switching

        Central ON/OFF commands

        Scene control

        Status reporting

        Switching delay

        Staircase lighting functions

        Logic operations

        Electrical Specifications

        Bus Voltage: KNX 21…30 VDC

        Power Supply: KNX bus powered

        Rated Frequency: 50/60 Hz

        Switching Capacity: Up to 16 AX / 20 AX depending on load type

        Protection: Electronic overload and thermal protection features

        Mechanical Specifications

        Mounting: DIN rail (TH35)

        Width: 4 modular units (4 MW)

        Dimensions: Approx. 72 × 90 × 60 mm

        Installation Location:

        Electrical distribution cabinets

        Building automation control panels

        Features & Advantages

        KNX Standard Integration

        Compatible with standard KNX building automation networks.

        High Load Switching Capability

        Supports switching of high-current electrical loads.

        Flexible Automation Control

        Can be programmed for different building control applications.

        Compact DIN Rail Design

        Easy installation inside electrical cabinets.

        Reliable Siemens Engineering

        Designed for long-term building automation operation.

        Typical Applications

        Smart buildings

        Office lighting control

        Commercial buildings

        Hotels

        Schools

        HVAC electrical control

        Energy management systems

        Compatible Equipment

        Commonly used with:

        Siemens GAMMA KNX systems

        KNX sensors

        KNX room controllers

        KNX touch panels

        Building management systems (BMS)

        Installation Precautions

        Confirm this model is a switching actuator, not a binary input module.

        Verify AC 230 V wiring before installation.

        Do not connect KNX bus terminals to power terminals.

        Check maximum load current ratings.

        Configure the device using ETS software.

        Ensure proper DIN rail mounting and cabinet ventilation.
