- - - - SIEMENS 3RT2636-1AP03 Contactor

        Product Overview

        SIEMENS 3RT2636-1AP03 is a SIRIUS 3RT26 Capacitor Contactor designed specifically for switching capacitive loads (AC-6b), such as power factor correction capacitor banks. It is a 3-pole contactor, size S2, equipped with pre-charge damping resistors to reduce inrush current when switching capacitor loads.

        This model is rated for 50 kVAr capacitor switching at 400 V AC, with a 230 V AC coil (50 Hz) and 1NO + 1NC auxiliary contacts.

        Specifications

        Brand: SIEMENS

        Series: SIRIUS 3RT26

        Model: 3RT2636-1AP03

        Product Type: Capacitor Contactor

        Application Category: AC-6b (Capacitive Loads)

        Number of Poles: 3 Pole

        Size: S2

        Rated Capacitor Power: 50 kVAr at 400 V AC

        Rated Voltage: Up to 690 V AC

        Coil Voltage: 230 V AC

        Frequency: 50 Hz

        Auxiliary Contacts: 1 NO + 1 NC

        Terminal Type: Screw Terminal

        Mounting: Panel / DIN rail compatible with accessories

        Operating Temperature: -25…+60 °C

        Protection Rating: IP20

        Advantages & Features

        Specially designed for capacitor bank switching

        Reduces capacitor switching surge current

        Improves power factor correction system reliability

        Integrated damping resistors protect capacitor components

        High switching reliability and long service life

        Compact SIRIUS modular design

        Provides auxiliary contacts for control and feedback circuits

        Suitable for industrial power compensation systems

        Applications

        Power factor correction cabinets

        Capacitor bank control systems

        Industrial electrical distribution

        Motor compensation systems

        Factory power management systems

        Automation control panels

        Low-voltage switchgear systems

        Precautions

        Confirm capacitor power rating before installation

        Do not use as a standard motor contactor

        Verify coil voltage (230 V AC, 50 Hz)

        Ensure correct capacitor discharge time before switching

        Check terminal tightening torque

        Disconnect power before maintenance

        Install with appropriate short-circuit protection
