- SIEMENS 3RP1525-1AP30 Timing Relay

  Product Overview

  SIEMENS 3RP1525-1AP30 is a SIRIUS electronic timing relay (time-delay relay) used in industrial control circuits for providing accurate time delay functions. It is an ON-delay (delayed energization) timing relay with a relay output and is designed for automation, motor control, and electrical control applications.

  This model provides 1 changeover contact (1CO), supports 15 selectable time ranges, and offers an adjustable delay range from 0.05 seconds to 100 hours.

  Specifications
  - Brand: SIEMENS
  - Series: SIRIUS 3RP15
  - Model: 3RP1525-1AP30
  - Product Type: Electronic Timing Relay
  - Function: ON Delay (Delay on Energization)
  - Contact Configuration: 1 Changeover Contact (1CO / SPDT)
  - Time Ranges: 15 selectable ranges
  - Adjustable Time Range: 0.05 s … 100 h
  - Supply Voltage:
    - 24 V AC
    - 200…240 V AC
    - 24 V DC
  - Frequency: 50/60 Hz
  - Output Type: Relay Output
  - Rated Thermal Current: 5 A
  - Connection Type: Screw Terminal
  - LED Indicator: Yes
  - Mounting: DIN Rail Mounting
  - Protection Rating:
    - Front: IP40
    - Terminals: IP20
  - Mechanical Life: Approx. 10 million operations
  - Electrical Life: Approx. 100,000 operations (AC-15, 230 V)
  Advantages & Features
  - Precise electronic timing control
  - Wide adjustable delay range from milliseconds to hours
  - Supports multiple timing ranges for flexible applications
  - Compact SIRIUS design for control cabinets
  - LED status indication for easy troubleshooting
  - Reliable relay output for industrial switching
  - Suitable for Siemens automation systems
  - Easy DIN rail installation
  Applications
  - Motor starting and stopping delay control
  - Star-delta starter circuits
  - Industrial automation equipment
  - PLC interface circuits
  - Conveyor systems
  - Pump and fan control systems
  - Machine control panels
  - Electrical control cabinets
  Precautions
  - Confirm supply voltage before installation
  - Set the correct time range before operation
  - Check relay contact rating before connecting loads
  - Ensure correct terminal wiring
  - Disconnect power before maintenance
  - Avoid exceeding the rated switching current
