SIEMENS 1P6RA8000-0MV62-0AA0-Z DC Drive Module

Product Description

SIEMENS 6RA8000-0MV62-0AA0-Z (often written as 1P6RA8000-0MV62-0AA0-Z) is a SINAMICS DCM DC Drive Control Module designed for controlling DC motors in industrial applications. It provides precise speed, torque, and current control for DC drive systems and includes a controllable field rectifier. The “-Z” suffix indicates customer-specific options added to the standard order number.

Specifications

• Brand: SIEMENS
• Model: 6RA8000-0MV62-0AA0-Z
• Series: SINAMICS DCM
• Product Type: DC Drive Control Module
• Rated Armature Supply Voltage: 50 / 125 / 250 / 575 / 1000 V AC (3-phase)
• Rated Field Supply Voltage: 480 V AC ±10/-20%
• Rated Field Current: 40 A
• Rated DC Field Voltage: Max. 390 V DC
• Control Power Supply: 24 V DC (18–30 V DC)
• Frequency: 45–65 Hz
• Operating Temperature: 0…+55 °C
• Installation: Control cabinet mounting
• Approx. Weight: 12 kg
• Function: DC motor speed, torque, and field control

Advantages & Features

• High-precision DC motor control performance
• Provides stable speed and torque regulation
• Integrated field control for DC motors
• Supports flexible configuration options through SINAMICS DCM platform
• Reliable operation in demanding industrial environments
• Easy integration into automation systems
• Suitable for modernization and replacement of existing DC drive systems

Applications

• Steel and metal processing equipment
• Paper and printing machinery
• Cranes and lifting systems
• Conveyor systems
• Mining equipment
• Industrial production lines
• Large DC motor drive applications

Notes

• Confirm exact option codes after the “-Z” suffix before replacement
• Check motor voltage, current, and field parameters before commissioning
• Ensure correct wiring of armature and field circuits
• Disconnect power and discharge DC bus before maintenance
• Configuration should be performed using Siemens commissioning tools
• Installation should be completed by qualified electrical technicians
