SIEMENS 1FK7032-5AK71-1HH0 Servo Motor

Item NO.:
1FK7032-5AK71-1HH0
Market Price:
$500
Product Origin:
Germany
Color:
NEW
Product weight:
0.01KG
Lead Time:
In stock

Product Overview

The SIEMENS 1FK7032-5AK71-1HH0 is a SIMOTICS S 1FK7 Compact synchronous servo motor designed for high-precision motion-control applications. It is a naturally cooled, three-phase servo motor with a 0.50 kW rated output and 6,000 rpm rated speed.

Key Technical Specifications

Item	Specification
Brand	SIEMENS
Model	1FK7032-5AK71-1HH0
Series	SIMOTICS S 1FK7
Product Type	Synchronous Servo Motor
Motor Type	3-Phase Permanent-Magnet Synchronous Motor
Rated Output	0.50 kW
Rated Speed	6,000 rpm
Rated Torque	0.8 Nm
Static Torque	1.10 Nm
Rated Current	Approx. 1.4 A
Maximum Mechanical Speed	10,000 rpm
Maximum Torque	4.5 Nm
Frame / Shaft Height	36 mm
Cooling	Naturally Cooled / Non-Ventilated
Mounting	IM B5 (IM V1, IM V3)
Encoder	Absolute Encoder A-512, 512 pulses/rev
Encoder Interface	EnDat, without DRIVE-CLiQ
Shaft	Smooth Shaft, Tolerance N
Holding Brake	Yes
Protection Rating	IP64
Connection	Power and signal connectors, connector rotatable 270°
DC Link Voltage	600 V DC

Siemens data for the 1FK7032-5AK71 family confirms 6,000 rpm, 0.8 Nm rated torque, 0.50 kW optimum power and a 36 mm shaft height; the exact -1HH0 configuration is specified with the A-512 absolute encoder, smooth shaft, holding brake and IP64 protection.
