Siemens 1FK7022-5AK71-1AA0 SIMOTICS Servo Motor

Siemens 1FK7022-5AK71-1AA0 SIMOTICS Servo Motor

Product Overview

The Siemens 1FK7022-5AK71-1AA0 is a SIMOTICS S-1FK7 Compact synchronous servo motor designed for high-precision motion control applications. It features a permanent magnet synchronous motor design, natural cooling, and is optimized for use with SINAMICS S120 servo drives in industrial automation systems.

Main Specifications

• Manufacturer: Siemens
• Model: 1FK7022-5AK71-1AA0
• Product Type: AC Servo Motor
• Series: SIMOTICS S-1FK7 Compact
• Motor Type:
  • Permanent magnet synchronous motor
• Rated Power: 0.38 kW
• Rated Speed: 6000 rpm
• Rated Torque: 0.6 Nm
• Static Torque:
  • Up to 0.85 Nm
• Rated Current: Approx. 1.4 A
• Cooling Method:
  • Natural cooling
• Frame Size: 28
• Mounting:
  • IM B5 (IM V1 / IM V3)
• Encoder:
  • Depending on configuration
• Degree of Protection:
  • IP64/IP65 depending on option configuration

Advantages & Features

• High dynamic response for precise positioning
• Compact and lightweight design
• High torque density and excellent efficiency
• Smooth operation with low vibration
• Suitable for high-speed motion applications
• Compatible with Siemens SINAMICS drive systems
• Reliable Siemens SIMOTICS industrial motor technology
• Easy integration into automated machinery

Applications

• CNC machine tools
• Robotics systems
• Packaging machinery
• Semiconductor equipment
• Pick-and-place systems
• Printing machinery
• Precision assembly equipment
• Factory automation systems

Important Notes

• Confirm compatibility with the correct Siemens servo drive before installation.
• Check encoder type and feedback interface when replacing motors.
• Ensure motor parameters are correctly configured in the drive.
• Verify mechanical mounting dimensions and shaft coupling.
• Avoid operation beyond rated torque and speed limits.
