SICK LMS500-21000 Lite (2D LiDAR Laser Measurement Sensor)



Product Overview

The SICK LMS500-21000 Lite is a high-performance 2D LiDAR laser measurement sensor used for distance measurement, contour detection, and area scanning in industrial automation.

It belongs to the SICK LMS5xx series, designed for indoor measurement and monitoring applications (non-safety version).

Key Specifications

• Brand: SICK
• Model: LMS500-21000 Lite
• Series: LMS5xx / LMS500
• Type: 2D LiDAR measurement sensor (not safety scanner)
• Laser Wavelength: 905 nm infrared laser
• Laser Class: Class 1 (eye safe)
• Scanning Angle: 190° horizontal
• Working Range: 0.2 m to 80 m
• Effective range (10% reflectivity): up to 26 m
• Accuracy: approx. ±12 mm
• Scan Frequency: 25 / 35 / 50 / 75 Hz selectable
• Angular Resolution: 0.25° / 0.5° / 1°
• Response Time: ~13 ms
• Housing: industrial IP65/industrial enclosure (variant dependent)

Working Principle

The LMS500 works by:

• Emitting a rotating laser beam (905 nm)
• Measuring time-of-flight reflection from objects
• Producing a 2D point cloud (radar-like scan)

It can:

• Detect object distance
• Generate contour profiles
• Measure position, shape, and movement
• Support field monitoring and classification

Key Features

• 190° wide-angle 2D scanning
• Long measurement range up to 80 m
• High accuracy (millimeter-level)
• Multiple scan frequencies for different speeds
• Multi-echo detection (improves reliability in dust/fog environments)
• Real-time data output for PLC / PC systems
• Suitable for industrial harsh environments

Advantages

• Very stable measurement in warehouse and factory environments
• Works on most surface types (metal, wood, cartons, etc.)
• High-speed scanning suitable for moving objects
• Strong resistance to ambient light interference
• Ideal for automation and AGV navigation
• Reliable long-distance detection capability

Applications

• AGV / AMR navigation systems
• Warehouse logistics and pallet detection
• Volume and contour measurement
• Industrial area monitoring
• Collision avoidance systems (non-safety use)
• Conveyor and material tracking
• Robotics environment mapping

Precautions

• This is a measurement LiDAR, not a safety-rated scanner
• Dust, steam, or heavy contamination may affect accuracy
• Reflectivity of target affects detection distance
• Requires stable mounting (vibration affects scan quality)
• Correct configuration is required for field evaluation mode
• Not intended for human safety protection applications
