SICK ATM60-P1H13X13 Absolute Encoder





Product Overview

The SICK ATM60-P1H13X13 is a high-performance absolute multiturn rotary encoder used for precise position and speed feedback in industrial automation systems.

It provides absolute position data even after power loss, making it suitable for servo systems, CNC machines, and heavy-duty motion control.

Key Specifications

• Brand: SICK
• Series: ATM60 PROFIBUS
• Model: ATM60-P1H13X13 (Order No. 1030014)
• Type: Absolute multiturn encoder
• Communication Interface: PROFIBUS DP (DPV0)

Performance

• Resolution: 13-bit singleturn + 13-bit multiturn (8192 × 8192)
• Total resolution: up to 26-bit absolute position
• Shaft type: Solid shaft, 6 mm diameter
• Max speed: up to 6000 rpm
• Supply voltage: 10–32 V DC
• Protection class: IP66 / IP67 (industrial rugged design)
• Operating temperature: -20°C to +85°C

Working Principle

The encoder uses magnetic absolute sensing technology:

• Singleturn section measures exact shaft position (13-bit)
• Multiturn section tracks number of revolutions (13-bit gear system)
• Output is transmitted via PROFIBUS DP fieldbus

Even if power is lost:

• Position is retained immediately after restart
• No homing required

Key Features

• Absolute multiturn position feedback (no battery required)
• High-resolution 26-bit system (8192 × 8192)
• PROFIBUS DP industrial communication
• Rugged IP66/IP67 housing for harsh environments
• High vibration and shock resistance
• Zero-set and preset functions available

Advantages

• Eliminates homing cycle after power loss
• High accuracy for servo positioning systems
• Strong reliability in heavy industrial environments
• Easy integration with PLC / motion control systems
• Long service life, maintenance-free design
• Suitable for harsh vibration applications

Applications

• CNC machine tools
• Servo motor feedback systems
• Robotics and automation lines
• Packaging and printing machinery
• Wind power and heavy industry equipment
• Conveyor and positioning systems

Precautions

• Must match correct PROFIBUS configuration and address setting
• Incorrect wiring may cause communication failure
• Shaft alignment must be precise to avoid mechanical damage
• Avoid exceeding allowable radial/axial shaft load
• Clean installation required to maintain IP67 protection
• Configuration tool may be required for parameter setup
