                            • SCHNEIDER TBUX297319 SCADAPack 5506 Analog Input Module

                              Correction: TBUX297319 is not a terminal module. It is the Schneider Electric SCADAPack 5506 8-channel analog input module. Schneider's official product page identifies it as an 8 AI I/O expansion module.

                              Key Technical Specifications

                              Parameter	Specification
                              Brand	Schneider Electric
                              Model	TBUX297319
                              Module Model	5506
                              Product Type	Analog Input Module
                              Number of Inputs	8
                              Input Type	Analog, single-ended
                              Current Inputs	0–20 mA / 4–20 mA
                              Voltage Inputs	0–5 V / 1–5 V
                              Resolution	15-bit
                              Accuracy	Approx. ±0.1% FS @ 25°C
                              Input Resistance	250 Ω current / 66 kΩ voltage
                              Isolation	500 VAC
                              Mounting	7.5 × 35 mm DIN rail
                              Dimensions	Approx. 74 × 124 × 45 mm
                              Operating Temperature	-40 to +70°C
                              Humidity	5–95% RH, non-condensing
                              Termination	10-pole removable terminal block
                              System	SCADAPack 47x / 57x / 500E / 300E / 300 / 32

                              Schneider documentation confirms the 8 analog inputs and supported ranges of 0–5 V, 1–5 V, 0–20 mA and 4–20 mA.

                              Advantages & Features

                              • 8-channel analog input expansion
                              • Supports both voltage and current signals
                              • 15-bit resolution for accurate process measurement
                              • Individually configurable input channels
                              • 500 VAC isolation
                              • DIN-rail mounting
                              • Removable terminal block for easier wiring
                              • Wide -40 to +70°C operating temperature range
                              • Designed for SCADAPack remote telemetry and RTU systems
                              • Suitable for hazardous-location applications with the appropriate certified system configuration.

                              Typical Applications

                              • SCADA and RTU systems
                              • Oil & gas monitoring
                              • Pipeline automation
                              • Water and wastewater systems
                              • Pumping stations
                              • Industrial process monitoring
                              • Remote pressure, flow and temperature measurement
                              • Utility and infrastructure monitoring

                              Important Precautions

                              • Verify the required signal type: 0–20 mA, 4–20 mA, 0–5 V or 1–5 V.
                              • Confirm compatibility with the installed SCADAPack controller.
                              • Do not exceed the specified input ranges.
                              • Check wiring polarity and channel configuration before commissioning.
                              • Use the correct removable terminal block and wiring accessories.
                              • Verify environmental and hazardous-area requirements for the installation.
