SCHNEIDER TBUX297247 Terminal Module
Item NO.:
TBUX297247Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
Correction: TBUX297247 is not a terminal module. It is a Schneider Electric SCADAPack 5405-24 high-density digital input expansion module with 32 discrete inputs for 12–24 VDC signals. Schneider's official product page identifies it as the Expansion Model 5405-24 D/I module.
| Parameter | Specification |
|---|---|
| Brand | Schneider Electric |
| Model | TBUX297247 |
| Module Model | 5405-24 |
| Product Type | Digital Input Expansion Module |
| System | SCADAPack 5000 Series |
| Number of Inputs | 32 |
| Input Type | Discrete / Digital |
| Input Voltage | 12–24 VDC |
| Input Groups | 4 isolated groups × 8 inputs |
| Isolation | 500 VAC/VDC from chassis and logic ground |
| Input Indicators | 32 red LEDs |
| Termination | 4 × 9-pin removable terminal blocks |
| Addressing | 4 DIP switches |
| Power Requirement | 5 VDC, approx. 10 mA |
| Dimensions | Approx. 144 × 127 × 45 mm |
| Operating Temperature | Approx. -40 to +60°C |
| Humidity | 5–95% RH, non-condensing |
| Mounting | SCADAPack I/O expansion system |
| Certification | UL508; hazardous-location ratings available |
Schneider documentation specifically lists TBUX297247 / 5405-24 as a 32-point, 12–24 VDC discrete-input module.
