SCHNEIDER SH31003P02A2000 Servo Motor

SCHNEIDER SH31003P02A2000 Servo Motor

Product Description

The SCHNEIDER SH31003P02A2000 is a Lexium SH3 AC servo motor designed for high-performance motion control applications. It features a 100 mm flange size, 8 Nm rated torque, 2400 W power, and an absolute multiturn SinCos encoder, providing precise positioning, high dynamic response, and reliable operation for industrial automation systems.

Technical Specifications

• Brand: Schneider Electric
• Model: SH31003P02A2000
• Product Type: AC Servo Motor
• Series: Lexium SH3
• Motor Size: IEC 100 mm flange
• Rated Power: 2.4 kW (2400 W)
• Rated Torque: 8 Nm
• Maximum Torque: Approx. 28.3 Nm
• Rated Speed: Up to 6000 rpm
• Supply Voltage: 115–480 VAC
• Motor Type: 3-phase AC servo motor
• Shaft Type: Smooth shaft (without key)
• Brake: Without brake
• Feedback Device: Absolute multiturn encoder, SinCos
• Encoder Resolution: 128-bit multiturn
• Connector: Rotatable right-angle connector
• Protection Rating: IP54 / IP65
• Mounting: Flange mounting

Advantages & Features

• High precision servo positioning performance
• Low inertia design for fast acceleration and deceleration
• High overload capability for demanding motion applications
• Absolute encoder eliminates the need for repeated homing after power cycles
• Compact Lexium SH3 design for easy machine integration
• Suitable for continuous industrial operation

Applications

• CNC machinery
• Packaging equipment
• Robotics and automated systems
• Semiconductor equipment
• Material handling systems
• Industrial motion control platforms
• Machine automation systems

Notes / Precautions

• Requires a compatible Schneider Lexium servo drive for operation.
• Confirm encoder type, motor parameters, and drive compatibility before replacement.
• This motor does not include an integrated holding brake.
• Check flange size, shaft type, and connector orientation before installation.
