SCHNEIDER LC1D300 Contactor

SCHNEIDER LC1D300 Contactor

Product Description

The SCHNEIDER LC1D300 is a TeSys D series heavy-duty AC contactor designed for high-power motor control and industrial switching applications. It is suitable for controlling large motors, heating systems, and industrial loads, providing reliable switching performance in demanding environments.

Technical Specifications

• Brand: Schneider Electric
• Model: LC1D300
• Product Type: AC Contactor
• Series: TeSys D
• Poles: 3 Pole (3NO)
• Rated Operational Current: 300 A (AC-3, application dependent)
• Rated Voltage: Up to 690 VAC
• Utilization Category: AC-3 / AC-3e
• Main Contact Configuration: 3 Normally Open
• Auxiliary Contacts: Depending on configuration/accessories
• Mounting: Panel mounting
• Terminal Type: Screw/clamp terminals
• Standard: IEC 60947-4-1

Advantages & Features

• Schneider TeSys D high-capacity contactor design
• Suitable for large motor switching applications
• High electrical and mechanical durability
• Reliable performance under frequent switching conditions
• Supports auxiliary contact and accessory expansion
• Designed for industrial control cabinets and power systems

Applications

• Large motor control systems
• Industrial machinery
• Pumps and compressors
• HVAC equipment
• Factory automation systems
• Power distribution control cabinets
• Heavy-duty electrical equipment

Notes / Precautions

• Confirm the coil voltage suffix before installation (LC1D300 alone does not specify the complete coil model).
• Check motor power, voltage, and operating category before replacement.
• Use appropriate overload protection with motor applications.
