  • SCHNEIDER LRD365 TeSys Thermal Overload Relay

    Product Overview

    The SCHNEIDER LRD365 is a TeSys Deca differential thermal overload relay designed for three-phase motor protection. It provides adjustable overload protection from 48 to 65 A and uses a Class 10A trip characteristic. Schneider specifies it for use with compatible TeSys D contactors.

    Key Technical Specifications

    Parameter	Specification
    Brand	Schneider Electric
    Model	LRD365
    Product Family	TeSys Deca / TeSys LRD
    Product Type	Thermal Overload Relay
    Application	Motor Protection
    Protection Type	Differential Thermal
    Current Adjustment Range	48–65 A
    Trip Class	Class 10A
    Number of Poles	3
    Rated Insulation Voltage	Up to 690 VAC IEC
    Auxiliary Contacts	1 NO + 1 NC
    Conventional Thermal Current	5 A
    Frequency	0–400 Hz
    Mounting	Direct mounting to compatible TeSys D contactor
    Terminal Type	EverLink
    Compatible Contactors	LC1D50A / LC1D65A
    Standards	IEC 60947-4-1

    Schneider confirms the 48–65 A adjustment range, Class 10A, 1NO+1NC auxiliary contacts, 690 V insulation rating, and TeSys D compatibility.

    Advantages & Features

    • Adjustable 48–65 A motor protection
    • Class 10A thermal overload protection
    • Differential phase-failure sensitivity
    • 1 NO + 1 NC auxiliary contacts
    • EverLink terminal technology
    • Direct connection to compatible TeSys D contactors
    • Suitable for industrial motor starter assemblies

    Typical Applications

    • Industrial motors
    • Pumps and fans
    • Compressors
    • Conveyors
    • Machine tools
    • Motor control panels
    • Factory automation systems

    Important Precautions

    • Set the overload current according to the motor's rated current.
    • Verify compatibility with the installed TeSys D contactor.
    • This device provides overload protection and should be used with appropriate short-circuit protection.
    • Ensure correct three-phase wiring and terminal tightening.
    • Installation should follow applicable electrical safety standards.
