SCHNEIDER LR97D015M7 Electronic Overload Relay
Item NO.:
LR97D015M7Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The SCHNEIDER LR97D015M7 is a TeSys LR97D electronic overcurrent/overload relay for motor protection. It provides protection against overload, locked rotor/mechanical jamming, and phase failure. The adjustable protection range is 0.3–1.5 A, with a 200–240 VAC relay supply.
| Parameter | Specification |
|---|---|
| Brand | Schneider Electric |
| Model | LR97D015M7 |
| Product Family | TeSys LR97D / TeSys D |
| Product Type | Electronic Overload / Overcurrent Relay |
| Rated Supply Voltage | 200–240 VAC |
| Frequency | 50/60 Hz |
| Adjustment Range | 0.3–1.5 A |
| Usable Protection Range | 0.3–1.3 A |
| Protection Functions | Overload, locked rotor, mechanical jamming, phase failure |
| Auxiliary Contacts | 1 C/O (1 NO + 1 NC) |
| Control Circuit Thermal Current | 3 A |
| Rated Operational Voltage | Up to 690 VAC |
| Mounting | Direct on contactor or DIN rail |
| Width | Approx. 45 mm |
| Compatible Contactors | TeSys D LC1D09–LC1D38 |
Schneider's documentation confirms the 0.3–1.5 A setting range, 200–240 VAC supply, 1 C/O contact arrangement, and LC1D09–D38 compatibility.
