SCHNEIDER ILE1B661PC1A0 Lexium Integrated Servo Motor

Product Overview

Brand: Schneider Electric
Model: ILE1B661PC1A0
Series: Lexium ILE Integrated Drive
Product Type: Integrated Servo Motor / Brushless DC Motor
Function: Compact motion control motor with built-in Profibus DP communication interface

Technical Specifications

• Motor Type: Brushless DC Servo Motor (EC Motor)
• Rated Voltage: 24...36 VDC
• Communication Interface: PROFIBUS DP integrated
• Motor Flange Size: 66 mm
• Motor Length: 122 mm
• Gearbox: Without gearbox
• Holding Brake: Without brake
• Number of Motor Poles: 6 poles
• Rated Speed:
  • 4000 rpm at 24 VDC
  • 4800 rpm at 36 VDC
• Rated Torque:
  • 0.175 N·m at 24 VDC
  • 0.24 N·m at 36 VDC
• Feedback Type: BLDC encoder
• Shaft Diameter: 8 mm
• Protection Rating: IP54
• Power Consumption: Approx. 70 W

Advantages & Features

• Integrated Drive Design
  Combines motor and drive electronics into one compact unit, reducing wiring and installation space.
• High Precision Motion Control
  Built-in encoder feedback provides accurate positioning and stable speed control.
• PROFIBUS DP Communication
  Enables easy integration into industrial automation networks.
• Compact and Lightweight Structure
  66 mm flange design is suitable for applications with limited installation space.
• Low Maintenance Brushless Technology
  Brushless DC motor design provides long service life and reliable operation.
• Flexible Control Performance
  Suitable for positioning, speed control, and motion automation applications.

Typical Applications

• Industrial automation equipment
• Packaging machinery
• Conveyor systems
• Material handling systems
• Assembly machines
• Robotics and positioning systems
• Medical and laboratory equipment

Precautions

• Confirm the power supply voltage is within 24...36 VDC range before operation.
• Ensure PROFIBUS DP communication settings match the control system.
• Avoid overload operation beyond rated torque limits.
• Install in a clean and ventilated environment.
• Check motor shaft alignment during installation.
• Disconnect power before maintenance or wiring changes.
• Verify compatibility with Schneider Lexium control systems before replacement.
