SCHNEIDER DL1BDM8 Harmony XVB LED Pilot Light Module

Product Overview

Brand: Schneider Electric
Model: DL1BDM8
Series: Harmony XVB
Product Type: LED Pilot Light Module / LED Bulb
Function: Yellow steady-light LED indicator module for visual signaling applications

Technical Specifications

• Light Source: LED
• Light Color: Yellow
• Lighting Mode: Steady light
• Rated Voltage: 230 VAC
• Current Consumption: 17 mA
• Lamp Base: BA15d
• Compatibility: Harmony XVB / XVP / XVD signaling systems
• Protection Type: Protected LED bulb
• Weight: Approx. 0.015 kg

Advantages & Features

• High Energy Efficiency
  LED technology provides low power consumption and long service life.
• Clear Visual Indication
  Bright yellow steady light improves equipment status visibility.
• Reliable Industrial Design
  Designed for Schneider Electric Harmony XVB signaling devices.
• Easy Replacement
  BA15d standard base allows quick installation and maintenance.
• Stable Operation
  Suitable for continuous industrial status indication applications.

Typical Applications

• Industrial control panels
• Factory automation equipment
• Machine status indication systems
• Electrical cabinets
• Production line warning systems
• Industrial signal towers and beacons

Precautions

• Verify voltage rating before installation (230 VAC).
• Ensure compatibility with the correct Harmony XVB/XVP/XVD series device.
• Disconnect power before replacing the LED module.
• Avoid installation in environments exceeding rated temperature or humidity limits.
• Do not use damaged LED modules.
